用于电化学检测羟基自由基的负载金纳米粒子的多孔聚乙二醇纳米片

Gold Nanoparticle-Loaded Porous Poly(ethylene glycol) Nanosheets for Electrochemical Detection of HO.

作者信息

Zhao Zhiyong, Zharnikov Michael

机构信息

Angewandte Physikalische Chemie, Universität Heidelberg, Im Neuenheimer Feld 253, 69120 Heidelberg, Germany.

出版信息

Nanomaterials (Basel). 2023 Dec 14;13(24):3137. doi: 10.3390/nano13243137.

Abstract

The effective detection of hydrogen peroxide (HO) in different environments and, above all, in biological media, is an important practical issue. To this end, we designed a novel electrochemical sensor for HO detection by introducing gold nanoparticles (AuNPs) into the porous poly(ethylene glycol) (PEG) matrix formed by the thermally activated crosslinking of amino- and epoxy-decorated STAR-PEG precursors. The respective composite PEG-AuNP films could be readily prepared on oxidized Si substrates, separated from them as free-standing nanosheets, and transferred as HO sensing elements onto the working electrode of the electrochemical cell, with the performance of the sensing element relied on the established catalytic activity of AuNPs with respect to HO decomposition. The sensitivity, detection limit, and the operation range of the composite PEG-AuNP sensors were estimated at ~3.4 × 10 μA mM cm, 0.17 μM of HO, and 20 μM-3.5 mM of HO, respectively, which are well comparable with the best values for other types of HO sensors reported recently in literature. The particular advantages of the composite PEG-AuNP sensors are commercial source materials, a simple fabrication procedure, the bioinert character of the PEG matrix, the 3D character of the AuNP assembly, and the possibility of transferring the nanosheet sensing element to any secondary substrate, including the glassy carbon electrode of the electrochemical cell. In particular, the bioinert character of the PEG matrix can be of importance for potential biological and biomedical applications of the designed sensing platform.

摘要

在不同环境中,尤其是在生物介质中有效检测过氧化氢(HO)是一个重要的实际问题。为此,我们通过将金纳米颗粒(AuNPs)引入由氨基和环氧修饰的STAR-PEG前体热活化交联形成的多孔聚乙二醇(PEG)基质中,设计了一种用于检测HO的新型电化学传感器。相应的复合PEG-AuNP薄膜可以很容易地在氧化硅基板上制备,从基板上分离成独立的纳米片,并作为HO传感元件转移到电化学池的工作电极上,传感元件的性能依赖于所建立的AuNPs对HO分解的催化活性。复合PEG-AuNP传感器的灵敏度、检测限和工作范围分别估计为~3.4×10 μA mM cm、0.17 μM的HO和20 μM - 3.5 mM的HO,与最近文献报道的其他类型HO传感器的最佳值相当。复合PEG-AuNP传感器的特别优点是原料来源商业化、制造过程简单、PEG基质的生物惰性、AuNP组装的三维特性以及将纳米片传感元件转移到任何二级基板(包括电化学池的玻碳电极)的可能性。特别是,PEG基质的生物惰性对于所设计传感平台的潜在生物和生物医学应用可能很重要。
