Kim Yeonjae, Seo Joo-Won, Lee In-Hee, Kim Jae-Yup
Department of Chemical Engineering, Dankook University, Yongin 16890, Republic of Korea.
Materials (Basel). 2023 Dec 31;17(1):225. doi: 10.3390/ma17010225.
To maximize the photoelectrochemical (PEC) hydrogen production performance of quantum dot (QD)-decorated photoelectrodes, it is crucial to prioritize the optimization of electrode's structure, including thickness and porosity. In this study, we prepare PbS QD-decorated mesoporous TiO photoanodes for PEC hydrogen production, and systematically investigate the influence of the photoanode thickness on optical properties and PEC performances. As the thickness of photoanodes increases from 6.4 µm to 16.3 µm, the light absorption capability is enhanced across the entire visible and near-infrared (IR) spectrum due to the improved loading of PbS QDs. However, the photocurrent density is optimized for the 11.9 µm thick photoanode (15.19 mA/cm), compared to the 6.4 µm thick (10.80 mA/cm) and 16.3 µm thick photoanodes (11.93 mA/cm). This optimization is attributed to the trade-off between the light absorption capability and the efficient mass transfer of the electrolyte as the photoanode thickness increases, which is confirmed by the lowest charge transfer resistance () evaluated from the electrochemical impedance data.
为了最大化量子点(QD)修饰光电极的光电化学(PEC)制氢性能,优先优化电极结构(包括厚度和孔隙率)至关重要。在本研究中,我们制备了用于PEC制氢的PbS QD修饰的介孔TiO光阳极,并系统地研究了光阳极厚度对光学性质和PEC性能的影响。随着光阳极厚度从6.4 µm增加到16.3 µm,由于PbS QDs负载量的提高,在整个可见光和近红外(IR)光谱范围内光吸收能力增强。然而,与6.4 µm厚(10.80 mA/cm²)和16.3 µm厚的光阳极(11.93 mA/cm²)相比,11.9 µm厚的光阳极的光电流密度达到最佳(15.19 mA/cm²)。这种优化归因于随着光阳极厚度增加,光吸收能力与电解质有效传质之间的权衡,这通过从电化学阻抗数据评估的最低电荷转移电阻得到证实。
