Tunnel construction in shallow soft rock using the pipe shed support.

In order to clarify the impact mechanism of shallow buried soft rock tunnel excavation on the upper existing highway, as well as the mechanism of pipe shed reinforcement, a combination of theoretical analysis and on-site monitoring was used to conduct in-depth research on the Diantou Tunnel Crossing the existing highway project of Dayong Expressway. The impact of shallow buried soft rock tunnel crossing construction on the existing highway and safety control issues were studied, a new deformation control index, namely deformation difference rate, was introduced. The results show that the main lateral area of influence of rock deformation is within a distance of one diameter, and the overall area of influence is within a distance of twice the diameter. From the perspective of axial tunnel deformation, the deformation of surrounding rock tends to be stable when the excavation face passes through the monitoring section about twice the tunnel diameter. Effectively controlling rock deformation depends on the total amount of settlement deformation, the change rate of deformation, and the difference rate of deformation. For V-class shallow buried tunnel surrounding rock, in order to prevent cracks on the surface, the cumulative deformation of the surrounding rock needs to be less than 50 mm, the change rate needs to be less than 3 mm/day, and the difference rate needs to be less than 5 mm/m. Finally, the proposed control standard for surface subsidence is given for similar engineering reference.
