Quantification of ssDNA Scaffold Production by Ion-Pair Reverse Phase Chromatography.

DNA origami is an emerging technology that can be used as a nanoscale platform in numerous applications ranging from drug delivery systems to biosensors. The DNA nanostructures are assembled from large single-stranded DNA (ssDNA) scaffolds, ranging from hundreds to thousands of nucleotides and from short staple strands. Scaffolds are usually obtained by asymmetric PCR (aPCR) or infection/transformation with phages or phagemids. Scaffold quantification is typically based on agarose gel electrophoresis densitometry for molecules obtained by aPCR, or by UV absorbance, in the case of scaffolds obtained by infection or transformation. Although these methods are well-established and easy-to-apply, the results obtained are often inaccurate due to the lack of selectivity and sensitivity in the presence of impurities. Herein, we present an HPLC method based on ion-pair reversed-phase (IP-RP) chromatography to quantify DNA scaffolds. Using IP-RP chromatography, ssDNA products (449 and 1000 nt) prepared by aPCR were separated from impurities and from the double stranded (ds) DNA byproduct. Additionally, both ss and dsDNA were quantified with high accuracy. The method was used to guide the optimization of the production of ssDNA by aPCR, which targeted the maximization of the ratio of ssDNA to dsDNA obtained. Moreover, ssDNA produced from phage infection of cells was also quantified by IP-RP using commercial ssDNA from the M13mp18 phage as a standard.
