Investigation of the mechanical behavior of rock-like material with two flaws subjected to biaxial compression.

The biaxial compression experiments of rock-like materials with two flaws are carried out under different flaw inclination angle, rock bridge ligament angle, lateral stress. The experimental studies show that crack propagation modes of rock-like material are as follows: wing crack through mode (Y mode), shear crack through mode (J mode), mixed crack through mode (wing shear JY mode), longitudinal extension of crack and transverse shear splitting. prefabricated fractured rock specimens have experienced the closing stage of prefabricated fractures, the elastic deformation stage, the generation and expansion of cracks (or plastic strengthening), and the residual loading stage. The peak strength of the specimen is increases with the increase of flaw inclination angle and lateral stress. With the increase of the rock bridge ligament angle, the failure of the rock bridge region changes from the shear crack failure to composite failure of shear crack and the wing type tensile crack failure, and then to the wing crack failure. With the increase of the lateral pressure, the failure of the specimen changes from the wing type tensile crack failure to the wing type and shear crack failure, and then to shear crack failure. The flaw inclination angle mainly changes the form of crack growth but does not effect on the failure modes. The counting number of acoustic emission events at the center of the sample is relative large, indicating that the cacks appear in the part of the rock bridge firstly. With the increasing of loads, the cracks of the rock bridge expanding constantly and connecting finally. The changes of acoustic emission event counts is consistent with the macroscopic damage form obtained from the experiments.
