Ma Dandan, Yin Xiangyu, Li Xinyi, Qin Xiangge, Qi Meili
School of Materials Science and Engineering, Jiamusi University, Jiamusi 154007, China.
School of Information Science and Electronic Technology, Jiamusi University, Jiamusi 154007, China.
Polymers (Basel). 2024 Jun 28;16(13):1856. doi: 10.3390/polym16131856.
Manganese dioxide is an ideal anode for sodium-ion batteries due to its rich crystal shapes. However, its low conductivity, low reversible discharge capacity, slow diffusion kinetics, and poor cyclic stability limit its potential for industrial application. The design of manganese dioxide (MnO) with various morphologies, such as nanowires, nanorods, and nanoflowers, has proven effective in enhancing its electrochemical performance. Stacking nanowire structures is of interest as they increase the open space by forming an interconnected network, thus facilitating favorable diffusion pathways for sodium ions. Concurrently, the substantial increase in the electrolyte contact area efficiently mitigates the strain induced by the volume expansion associated with the repetitive migration and insertion of sodium ions. Based on previous research, this work presents the structural design of flexible MnO/polyaniline (MnO/PANI) nanowires assembled on carbon cloth (CC), an innovation in MnO modification. Compared to conventional MnO nanowires, the MnO/PANI nanowires exhibit enhanced structural stability and improved dynamic performance, thereby marking a significant advancement in their material properties. This MnO/PANI composite exhibits a rate capacity of approximately 200 mA h g after 60 cycles at a current density of 0.1 A g, and maintains a rate capacity of 182 mA h g even after 200 cycles under the same current density. This study not only provides new insights into the underlying mechanisms governing energy storage in MnO/PANI nanowires but also paves the way for their further development and optimization as anodes for sodium-ion batteries, thereby opening up fresh avenues for research and application.
二氧化锰因其丰富的晶体形状而成为钠离子电池的理想阳极。然而,其低导电性、低可逆放电容量、缓慢的扩散动力学和较差的循环稳定性限制了其工业应用潜力。设计具有各种形态的二氧化锰(MnO),如纳米线、纳米棒和纳米花,已被证明能有效提高其电化学性能。堆叠纳米线结构备受关注,因为它们通过形成相互连接的网络增加了开放空间,从而为钠离子提供了有利的扩散途径。同时,电解质接触面积的大幅增加有效地减轻了与钠离子的重复迁移和嵌入相关的体积膨胀所引起的应变。基于先前的研究,这项工作提出了在碳布(CC)上组装的柔性MnO/聚苯胺(MnO/PANI)纳米线的结构设计,这是MnO改性方面的一项创新。与传统的MnO纳米线相比,MnO/PANI纳米线表现出增强的结构稳定性和改善的动态性能,从而在其材料性能方面取得了重大进展。这种MnO/PANI复合材料在0.1 A g的电流密度下循环60次后,倍率容量约为200 mA h g,即使在相同电流密度下循环200次后仍保持182 mA h g的倍率容量。这项研究不仅为MnO/PANI纳米线储能的潜在机制提供了新的见解,也为其作为钠离子电池阳极的进一步开发和优化铺平了道路,从而开辟了新的研究和应用途径。
