[Determination of seven phenoxy carboxylic acid herbicides in water using dispersive solid phase extraction coupled with ultra-high performance liquid chromatography-tandem mass spectrometry based on metal-organic framework composite aerogel].

作者信息

Zhang Xin, Wu Ge-Ge, Cui Wen-Lian, Li Shuang, Ma Ji-Ping

机构信息

College of Environmental and Municipal Engineering, Qingdao University of Technology, Qingdao 266000, China.

Qingdao Ecological Environment Monitoring Center of Shandong Province, Qingdao 266000, China.

出版信息

Se Pu. 2024 Nov;42(11):1042-1051. doi: 10.3724/SP.J.1123.2024.01005.


DOI:10.3724/SP.J.1123.2024.01005
PMID:39449511
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC11519771/
Abstract

Phenoxy carboxylic acid herbicides (PCAs) are difficult to degrade and, thus, pose significant threats to the environment and human health. The limit for 2,4-dichlorophenoxyacetic acid is 30 μg/L in China's standards for drinking water quality, 70 μg/L in the United States' drinking water standards, and 30 μg/L in the World Health Organization's guidelines for drinking water quality. Therefore, the development of an effective detection method for trace PCAs in water is a crucial endeavor. Metal-organic frameworks (MOFs) are novel porous materials that possess advantages such as a large specific surface area, adjustable pore size, and abundant active sites. They exhibit excellent adsorption capability for various compounds. However, the applications of MOFs as adsorbents are limited. For example, the process of isolating powdered MOFs from aqueous solutions is laborious, and microporous MOFs exhibit limited surface affinity, which decreases their mass transfer efficiency in the liquid phase. MOF crystals can be embedded in a substrate to overcome these limitations. Aerogels are obtained by drying hydrogels, which are hydrophilic polymers with a three-dimensional crosslinked network structure. Spongy aerogel materials exhibit unique structural properties such as high porosity, large pore volume, ultralow density, and easy tailorability. When MOFs are combined with an aerogel, their efficient and selective adsorption properties are preserved. In addition, MOF aerogels exhibit a hierarchical porous structure, which enhances the affinity and mass transfer efficiency of the MOF for target molecules. At present, MOF aerogels are primarily prepared by freeze-drying or using supercritical carbon dioxide. These drying processes require significant amounts of energy and time. Hence, the development of greener and more efficient methods to prepare skeleton aerogels is urgently needed. In this study, we prepared an environment-friendly aerogel at ambient temperature and pressure without the use of specialized drying equipment. This ambient-dried MOF composite aerogel was then used for the dispersive solid phase extraction (DSPE) of seven PCAs from environmental water, followed by ultra-high performance liquid chromatography-tandem mass spectrometry (UHPLC-MS/MS). The key parameters affecting the efficiency of DSPE, including the extraction conditions, ratio of MIL-101(Fe)-NH to sodium alginate, pH of the aqueous samples, extraction time, ionic strength (salinity), and elution conditions, such as the elution solvent ratio, elution time, and elution volume, were investigated to obtain optimal extraction efficiency. The adsorbent could adsorb the target contaminants within 12 min, and the analytes could be completely desorbed within 30 s by elution with 4 mL of 1.5% (v/v) formic acid in methanol solution. The water samples could be analyzed without pH adjustment. The main adsorption mechanisms were electrostatic interactions and conjugation. Thus, a new method based on MOF aerogels coupled with UHPLC-MS/MS was developed for the determination of the seven PCA residues in water. The calibration curves for the seven PCAs showed good linearity (≥0.9986), with limits of detection (LODs) and quantification (LOQs) ranging from 0.30 to 1.52 ng/L and from 1.00 to 5.00 ng/L, respectively. Good intra- and inter-day precision values of 6.5%-17.1% and 7.4%-19.4%, respectively, were achieved under low (8 ng/L), medium (80 ng/L), and high (800 ng/L) spiking levels. The developed method was applied to the detection of PCAs in surface water, seawater, and waste leachate, and the detected mass concentrations ranged from 0.6 to 19.3 ng/L. Spiked recovery experiments were conducted at mass concentrations of 8, 80, and 800 ng/L, and the recoveries ranged from 61.7% to 120.3%. The proposed method demonstrates good sensitivity, precision, and accuracy, and has potential applications in the detection of trace PCAs in environmental water.

摘要
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/523c43edacf6/cjc-42-11-1042-img_6.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/7d917ccb833f/cjc-42-11-1042-img_1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/768df19fa6c4/cjc-42-11-1042-img_2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/c5e3a66d6cdf/cjc-42-11-1042-img_3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/5779c1085c34/cjc-42-11-1042-img_4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/a0f66390db48/cjc-42-11-1042-img_5.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/523c43edacf6/cjc-42-11-1042-img_6.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/7d917ccb833f/cjc-42-11-1042-img_1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/768df19fa6c4/cjc-42-11-1042-img_2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/c5e3a66d6cdf/cjc-42-11-1042-img_3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/5779c1085c34/cjc-42-11-1042-img_4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/a0f66390db48/cjc-42-11-1042-img_5.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/248c/11519771/523c43edacf6/cjc-42-11-1042-img_6.jpg
