不同来源沼液液体部分的提纯——用于此目的的聚合物和陶瓷超滤膜的比较

Purification of Liquid Fraction of Digestates from Different Origins-Comparison of Polymeric and Ceramic Ultrafiltration Membranes Used for This Purpose.

作者信息

Urbanowska Agnieszka

机构信息

Department of Water, Wastewater and Waste Technology, Faculty of Environmental Engineering, Wroclaw University of Science and Technology, Wybrzeze Wyspianskiego 27, 50-370 Wroclaw, Poland.

出版信息

Membranes (Basel). 2024 Sep 25;14(10):203. doi: 10.3390/membranes14100203.

DOI:10.3390/membranes14100203
PMID:39452815
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC11509311/
Abstract

Circular economy, clean technologies, and renewable energy are key to climate protection and modern environmental technology. Recovering water and valuable minerals from the liquid fraction of digestate is in line with this strategy. Digestate, a byproduct of anaerobic methane fermentation in biogas plants, is a potential source of water, minerals for fertilizers, and energy rather than waste. This study examined digestate from municipal and agricultural biogas plants and highlights the need for research on both due to their differences. The use of membrane techniques for water recovery from liquid digestate offers an innovative alternative to conventional methods. This study used standalone membrane filtration and an integrated system to produce water suitable for agricultural use. Ceramic membranes with cut-offs of 1, 5, 15, and 50 kDa and polymeric membranes of polyethersulfone and regenerated cellulose with cut-offs of 10 and 30 kDa were tested. The results showed that the membrane material significantly affects the transport and separation properties. Higher cut-off values increased permeate flux across all membranes. Ceramic membranes were more susceptible to fouling in standalone ultrafiltration, but were more effective in purifying digestate than polymeric membranes. The best results were obtained with a ceramic membrane with a 1 kDa cut-off (for example, for the integrated process and the municipal digestate, the retention rates of COD, BOD and DOC were 69%, 62%, and 75%, respectively).

摘要

循环经济、清洁技术和可再生能源是气候保护和现代环境技术的关键。从沼渣的液体部分回收水和有价值的矿物质符合这一战略。沼渣是沼气厂厌氧甲烷发酵的副产品,是水、肥料矿物质和能源的潜在来源,而非废物。本研究检测了城市和农业沼气厂的沼渣,并强调了由于两者存在差异,对其进行研究的必要性。使用膜技术从液体沼渣中回收水为传统方法提供了一种创新替代方案。本研究采用独立膜过滤和集成系统来生产适合农业使用的水。测试了截留分子量为1、5、15和50 kDa的陶瓷膜以及截留分子量为10和30 kDa的聚醚砜和再生纤维素聚合物膜。结果表明,膜材料显著影响传输和分离性能。较高的截留值增加了所有膜的渗透通量。在独立超滤中,陶瓷膜更容易受到污染,但在净化沼渣方面比聚合物膜更有效。截留分子量为1 kDa的陶瓷膜取得了最佳效果(例如,对于集成工艺和城市沼渣,COD、BOD和DOC的截留率分别为69%、62%和75%)。
