Li Yuanzhe, Lee Yaerim, Fujikawa Shota, Shen Jiaxing, Sasaki Shota, Matsuzaki Masaki, Matsui Norizumi, Hosomi Takuro, Yanagida Takeshi, Shiomi Junichiro
Institute of Engineering Innovation, Graduate School of Engineering, The University of Tokyo, Tokyo 113-8656, Japan.
Department of Mechanical Engineering, Graduate School of Engineering, The University of Tokyo, Tokyo 113-8656, Japan.
ACS Appl Mater Interfaces. 2024 Nov 13;16(45):63039-63048. doi: 10.1021/acsami.4c15331. Epub 2024 Nov 1.
Slippery solid surfaces with low droplet contact angle hysteresis (CAH) are crucial for applications in thermal management, energy harvesting, and environmental remediation. Traditionally, reducing CAH has been achieved by enhancing surface homogeneity. This work challenges this conventional approach by developing slippery yet hydrophilic surfaces through hybrid monolayers composed of hydrophilic polyethylene glycol (PEG)-silane and hydrophobic alkyl-silane molecules. These hybrid surfaces exhibited exceptionally low CAH (<2°), outperforming well-established homogeneous slippery surfaces. Molecular structural analyses suggested that the remarkable slipperiness is due to a unique spatially staggered molecular configuration, where longer PEG chains shield shorter alkyl chains, thus creating additional free volume while ensuring surface coverage. This was supported by the observation of decreased CAH with increasing temperature, highlighting the role of grafted chain mobility in enhancing slipperiness by self-smoothing and fluid-like behaviors. Furthermore, condensation experiments demonstrated the exceptional performance of the hydrophilic slippery surfaces in dew harvesting due to superior condensation nucleation, droplet coalescence, and self-sweeping efficiency. These findings offer a novel paradigm for designing advanced slippery surfaces and provide valuable insights into the molecular mechanisms governing dynamic wetting.
具有低液滴接触角滞后(CAH)的光滑固体表面对于热管理、能量收集和环境修复等应用至关重要。传统上,降低CAH是通过提高表面均匀性来实现的。这项工作通过由亲水性聚乙二醇(PEG)-硅烷和疏水性烷基硅烷分子组成的混合单分子层开发出光滑但亲水性的表面,对这种传统方法提出了挑战。这些混合表面表现出极低的CAH(<2°),优于成熟的均匀光滑表面。分子结构分析表明,显著的光滑性归因于独特的空间交错分子构型,其中较长的PEG链屏蔽较短的烷基链,从而在确保表面覆盖的同时创造额外的自由体积。随着温度升高CAH降低的观察结果支持了这一点,突出了接枝链流动性通过自平滑和类流体行为增强光滑性的作用。此外,冷凝实验表明,由于卓越的冷凝成核、液滴聚结和自清扫效率,亲水性光滑表面在露水收集方面具有出色的性能。这些发现为设计先进的光滑表面提供了一种新的范例,并为控制动态润湿的分子机制提供了有价值的见解。
