Sitnova A V, Valitov E R, Svetozarskiy S N
Clinical Resident, Department of Eye Diseases; The S. Fyodorov Eye Microsurgery Federal State Institution, 59a Beskudnikovsky Blvd., Moscow, 127486, Russia.
Teacher, Computer Sciences Chair, Department of Big Data and Information Retrieval; National Research University Higher School of Economics, 20 Myasnitskaya St., Moscow, 101000, Russia.
Sovrem Tekhnologii Med. 2024;16(4):5-13. doi: 10.17691/stm2024.16.4.01. Epub 2024 Aug 30.
is to develop a method for diagnosing fungal keratitis based on the analysis of photographs of the anterior segment of the eye using deep learning algorithms with subsequent evaluation of sensitivity and specificity of the method on a test data set in comparison with the results of practicing ophthalmologists.
The study has included the stages of data acquisition, image pre-training and markup, selection of training approach and neural network architecture, training with input data augmentation, validation with hyperparameter correction, evaluation of algorithm performance on a test sample, and determination of sensitivity and specificity of fungal keratitis detection by practicing doctors. A total of 274 anterior segment images were used, including 130 photographs of the eyes affected by fungal keratitis and 144 photographs illustrating normal eyes, keratitis of other etiologies, and various anterior segment pathologies. Photographs taken after the treatment onset, illustrations of keratitis of mixed etiology and corneal perforation were excluded from the study. Images of the training sample were marked up using the VGG Image Annotator web application and then used to train the YOLOv8 convolutional neural network. Images from the test data set were also offered to practicing ophthalmologists to determine the diagnostic accuracy of fungal keratitis.
The sensitivity of the model was 56.0%, the specificity level reached 96.1%, and the proportion of correct answers of the algorithm was 76.5%. The accuracy of image recognition by practicing ophthalmologists was 50.0%, specificity - 41.7%, sensitivity - 57.7%.
The study showed the high potential of deep learning algorithms in the diagnosis of fungal keratitis and its advantages in accuracy compared to expert judgment in the absence of metadata. The use of computer vision technologies may find application as a complementary diagnostic method in decision making in complex cases and in telemedicine care settings. Further research is required to compare the developed model with alternative approaches, to expand and standardize databases.
旨在开发一种基于深度学习算法分析眼前节照片来诊断真菌性角膜炎的方法,并随后在测试数据集上评估该方法的敏感性和特异性,同时与眼科医生的诊断结果进行比较。
该研究包括数据采集、图像预训练和标注、训练方法和神经网络架构的选择、输入数据增强的训练、超参数校正的验证、测试样本上算法性能的评估以及执业医生检测真菌性角膜炎的敏感性和特异性的确定。总共使用了274张眼前节图像,其中包括130张受真菌性角膜炎影响的眼睛的照片以及144张说明正常眼睛、其他病因的角膜炎和各种眼前节病变的照片。研究排除了治疗开始后拍摄的照片、混合病因角膜炎和角膜穿孔的插图。使用VGG图像标注器网络应用程序对训练样本的图像进行标注,然后用于训练YOLOv8卷积神经网络。测试数据集的图像也提供给执业眼科医生,以确定真菌性角膜炎的诊断准确性。
该模型的敏感性为56.0%,特异性水平达到96.1%,算法的正确答案比例为76.5%。执业眼科医生的图像识别准确率为50.0%,特异性为41.7%,敏感性为57.7%。
该研究表明深度学习算法在真菌性角膜炎诊断中具有很高的潜力,并且在没有元数据的情况下与专家判断相比在准确性方面具有优势。计算机视觉技术的应用可能作为一种辅助诊断方法,用于复杂病例的决策和远程医疗护理环境。需要进一步研究将开发的模型与替代方法进行比较,以扩展和标准化数据库。
