利用解剖切片、计算机断层扫描和磁共振成像对正常鸵鸟头部进行结构研究。

Structural investigations of the normal ostrich head using anatomical sections, computed tomography, and magnetic resonance imaging.

作者信息

Aref Mohamed, Raouf Mustafa Abd El, Youssef Walaa O M, Abdelbaset-Ismail Ahmed, Salem Gamal A, Nassan Mohamed A, Rutland Catrin S, Mahdy Eman A A

机构信息

Department of Anatomy and Embryology, Faculty of Veterinary Medicine, Zagazig University, Zagazig, Egypt.

Department of Surgery, Faculty of Veterinary Medicine, Zagazig University, Zagazig, Egypt.

出版信息

Open Vet J. 2024 Dec;14(12):3487-3497. doi: 10.5455/OVJ.2024.v14.i12.32. Epub 2024 Dec 31.

DOI:10.5455/OVJ.2024.v14.i12.32
PMID:39927348
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC11799614/
Abstract

BACKGROUND

The significance of the ostrich (Struthio camelus) has increased recently due to the growth of the global ostrich farming industry. Morphological and diagnostic imaging of the ostrich head presents challenges for enhancing clinical treatment and veterinary care, particularly concerning surgical disorders in the head and paranasal sinuses.

AIM

This study aims to guide veterinarians in improving the accuracy of clinical diagnoses and treatment for upper respiratory tract and cranial conditions, particularly in surgical cases involving the head and paranasal sinuses.

METHODS

Ten healthy adult ostrich heads () were collected for anatomical examination. This sample consisted of 5 males (average age: 1.84 ± 0.32 years) and 5 age-matched females (average age: 2.02 ± 0.311 years). The study focused on the cranial, orbital, nasal, and oropharyngeal cavities, along with their contents and paranasal sinuses. The examination included the analysis of bony and cartilaginous structures, as well as soft tissues and cavities, using median, four sagittal, and five cross-anatomical sections. Subsequently, the specimens underwent diagnostic screening using CT and MRI.

RESULTS

Here, we found that the ostrich has two oval featherless nostrils covered by a characteristic operculum at its entrance. The nasal septum separates the nasal cavity, which is supported by the rostral cartilaginous part. There were three features of nasal conchae: rostral (T-shape), middle (coiled bullae), and caudal (triangular), which differ from other bird species. Two paranasal sinuses were detected including triangular-shaped infraorbital and two identical frontal sinuses. The maxillary rhamphotheca had a median culmen and lateral tomium, while the mandibular rhamphotheca also had a median gonys and lateral tomium. The brain was divided into the hindbrain (consisting of medulla oblongata and cerebellum), the midbrain (peduncles of the cerebrum and optic lobes), and the forebrain (thalamus, pineal body, hypophysis, optic tracts and chiasm, cerebral hemispheres, and olfactory lobes). All last structures were compared and verified by CT and MRI.

CONCLUSION

This study provides an atlas of anatomical cross-sections, CT, and MRI scans of the ostrich head, which can serve as valuable guidance for veterinarians to improve diagnoses and treatments, ultimately enhancing health outcomes for these birds.

摘要

背景

由于全球鸵鸟养殖业的发展,鸵鸟(鸵鸟属骆驼鸵鸟)的重要性近来有所增加。鸵鸟头部的形态学和诊断成像对加强临床治疗和兽医护理提出了挑战,特别是在涉及头部和鼻窦的外科疾病方面。

目的

本研究旨在指导兽医提高上呼吸道和颅骨疾病,特别是涉及头部和鼻窦的外科病例的临床诊断和治疗准确性。

方法

收集10个健康成年鸵鸟头部()进行解剖检查。该样本包括5只雄性(平均年龄:1.84±0.32岁)和5只年龄匹配的雌性(平均年龄:2.02±0.311岁)。研究重点关注颅腔、眶腔、鼻腔和口咽腔及其内容物和鼻窦。检查包括使用正中、四个矢状和五个交叉解剖切片分析骨和软骨结构以及软组织和腔隙。随后,对标本进行CT和MRI诊断筛查。

结果

在此,我们发现鸵鸟有两个椭圆形无毛鼻孔,其入口处有一个特征性的盖。鼻中隔将鼻腔分开,鼻腔由吻部软骨部分支撑。鼻甲有三个特征:吻部(T形)、中部(卷曲的大泡)和尾部(三角形),这与其他鸟类不同。检测到两个鼻窦,包括三角形的眶下窦和两个相同的额窦。上颌角质鞘有正中嵴和外侧缘,而下颌角质鞘也有正中颏和外侧缘。脑分为后脑(由延髓和小脑组成)、中脑(大脑脚和视叶)和前脑(丘脑、松果体、垂体、视束和交叉、大脑半球和嗅叶)。所有最后这些结构均通过CT和MRI进行了比较和验证。

结论

本研究提供了鸵鸟头部的解剖横断面图谱、CT和MRI扫描,可为兽医改善诊断和治疗提供有价值的指导,最终提高这些鸟类的健康水平。
