骨盆倾斜增加全髋关节置换术中撞击风险并改变撞击类型:一项个体化模拟研究

Pelvic Tilt Increases the Risk of Impingement and Alters Impingement Type in Total Hip Arthroplasty: A Patient-Specific Simulation Study.

作者信息

Palit Arnab, Williams Mark A, Seemala Vineet, Donnelly Mike, Renkawitz Tobias, Weber Markus

机构信息

WMG, The University of Warwick, Coventry, UK.

Department of Orthopaedic Surgery, Regensburg University, Regensburg, Bad Abbach, Germany.

出版信息

J Orthop Res. 2025 Jul;43(7):1303-1314. doi: 10.1002/jor.26085. Epub 2025 Apr 12.

DOI:10.1002/jor.26085
PMID:40221867
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC12159588/
Abstract

Impingement is a significant complication following total hip arthroplasty (THA), resulting in restricted range of motion (ROM). Pelvic tilt (PT) and its variation could alter both post-THA ROM and impingement types, which remains relatively unexplored in the literature. Therefore, this study aims to investigate the impact of PT changes on post-THA ROM and impingement types. Subject-specific ROM was simulated using 3D-CT and clinical data for 56 THA patients. Subsequently, the effect of no-PT, standing preoperative (StPT) and postoperative PT at 6 (StPT) and 12 months (StPT) on maximum ROM (flexion, extension, abduction, adduction, external rotation (ER) and internal rotation at 90° Flexion (IR@90°Flex)) and impingement types (implant-to-implant impingement (ITII), implant-to-bone impingement (ITBI), and bone-to-bone impingement (BTBI)) were investigated. Stong correlations existed between PT and flexion (R ≥ 0.686), extension (R ≥ 0.527), and IR@90°Flex (R ≥ 0.547). Anterior PT exceeding 8.1° and 11.8° were linked to decreased flexion below 110° and IR@90°Flex below 30°, respectively. Each 10° increase in anterior PT resulted in a 10° reduction in flexion and a 10.7° reduction in IR@90°Flex. Impingement types due to PT remained unchanged for flexion/extension, with increased ITII for abduction (8.9%), adduction (23.2%), and IR@90°Flex (16.1%), and increased BTBI (16.1%) for ER. In total, 12.5% and 19.6% of patients experienced clinically relevant ROM change for flexion and IR@90°Flex, respectively for StPT-StPT. However, it affected below 5.4% cases when comparing StPT and StPT. Minor changes in impingement type (< 6% of cases) were observed due to changes in PT before and after THA, as well as temporal changes in PT post-THA. However, PT had a substantial impact on impingement types when comparing ROM without considering PT to ROM with PT included. Specifically, anterior PT was associated with reduced flexion and IR@90°Flex, indicating a higher risk of impingement. PT changes over time may lead to clinically relevant alterations in ROM but not impingement types. Trial Registration: German Clinical Trials Register; Main ID: DRKS00000739.

摘要

撞击是全髋关节置换术(THA)后一种严重的并发症,会导致活动范围(ROM)受限。骨盆倾斜(PT)及其变化可能会改变THA后的ROM和撞击类型,而这在文献中相对未被充分探索。因此,本研究旨在调查PT变化对THA后ROM和撞击类型的影响。使用56例THA患者的3D-CT和临床数据模拟了个体特异性ROM。随后,研究了无PT、术前站立位(StPT)以及术后6个月(StPT)和12个月(StPT)时的PT对最大ROM(屈曲、伸展、外展、内收、外旋(ER)和90°屈曲时的内旋(IR@90°Flex))和撞击类型(植入物对植入物撞击(ITII)、植入物对骨撞击(ITBI)和骨对骨撞击(BTBI))的影响。PT与屈曲(R≥0.686)、伸展(R≥0.527)和IR@90°Flex(R≥0.547)之间存在强相关性。前PT超过8.1°和11.8°分别与屈曲低于110°和IR@90°Flex低于30°的减少有关。前PT每增加10°,屈曲减少10°,IR@90°Flex减少10.7°。由于PT导致的撞击类型在屈曲/伸展时保持不变,外展(8.9%)、内收(23.2%)和IR@90°Flex(16.1%)时ITII增加,ER时BTBI增加(16.1%)。总体而言,分别有12.5%和19.6%的患者在StPT-StPT时屈曲和IR@90°Flex出现了临床相关的ROM变化。然而,在比较StPT和StPT时,受影响的病例低于5.4%。由于THA前后PT的变化以及THA后PT的时间变化,观察到撞击类型有轻微变化(<6%的病例)。然而,在比较不考虑PT的ROM和包含PT的ROM时,PT对撞击类型有重大影响。具体而言,前PT与屈曲和IR@90°Flex的减少相关,表明撞击风险更高。PT随时间的变化可能导致ROM出现临床相关改变,但不会导致撞击类型改变。试验注册:德国临床试验注册中心;主要编号:DRKS00

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/7d992f938b88/JOR-43-1303-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/77bed574018d/JOR-43-1303-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/72abda28a002/JOR-43-1303-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/e55f6193a730/JOR-43-1303-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/dcc94e3dc18e/JOR-43-1303-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/d23e171c851a/JOR-43-1303-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/c4c2099c7cc7/JOR-43-1303-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/fe5f7e01003d/JOR-43-1303-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/f44b98ff576b/JOR-43-1303-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/eb1e90216ae7/JOR-43-1303-g010.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/7d992f938b88/JOR-43-1303-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/77bed574018d/JOR-43-1303-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/72abda28a002/JOR-43-1303-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/e55f6193a730/JOR-43-1303-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/dcc94e3dc18e/JOR-43-1303-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/d23e171c851a/JOR-43-1303-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/c4c2099c7cc7/JOR-43-1303-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/fe5f7e01003d/JOR-43-1303-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/f44b98ff576b/JOR-43-1303-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/eb1e90216ae7/JOR-43-1303-g010.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/51b2/12159588/7d992f938b88/JOR-43-1303-g004.jpg
