Zhong Jian, Duan Haiyan, Cai Mingquan, Zhu Ying, Wang Zhenlin, Li Xingchi, Zhang Zhengliang, Qu Wenqiang, Zhang Kai, Han Donglin, Cheng Danhong, Shen Yongjie, Xie Ming, Cortes Emiliano, Zhang Dengsong
International Joint Laboratory of Catalytic Chemistry, State Key Laboratory of Advanced Special Steel, Innovation Institute of Carbon Neutrality, Department of Chemistry, College of Sciences, Shanghai University, Shanghai, 200444, People's Republic of China.
Department of Chemistry, University of Toronto, 80 St. George Street, Toronto, ON, M5S 3H6, Canada.
Angew Chem Int Ed Engl. 2025 Aug 4;64(32):e202507956. doi: 10.1002/anie.202507956. Epub 2025 Jun 18.
Electrochemical nitrate reduction reaction (NORR) is a promising approach to simultaneously realize pollutant removal and ammonia generation. However, this process involves the transfer of eight electrons and nine protons along with multiple by-products, resulting in a significant challenge for achieving high ammonia yield and selectivity. Herein, we introduced bimetallic covalent organic frameworks catalysts with Cu and Co active sites to achieve a two-step tandem reaction, avoiding excessive nitrite accumulation and enabling efficient NORR. For the initial two-electron process, the Cu sites in the bimetallic catalyst exhibit a strong binding affinity with nitrate, promoting their conversion to nitrite. The Co sites enhance the supply and adsorption of active hydrogen and stabilize the subsequent six-electron process, thereby improving the overall catalytic efficiency. Compared to monometallic Cu and Co catalysts, the CuCo bimetallic catalyst demonstrates superior ammonia yield and Faradaic efficiency (NH yield rate = 20.8 mg·h·cm, FE = 92.16% in 0.3 M nitrate). Such coordinated two-step process advances the efficiency and applicability of NORR through optimizing a cascade catalytic reaction, thereby establishing an innovative path for the engineering of NORR electrocatalysts.
电化学硝酸盐还原反应(NORR)是一种有望同时实现污染物去除和氨生成的方法。然而,该过程涉及八个电子和九个质子的转移以及多种副产物,这给实现高氨产率和选择性带来了重大挑战。在此,我们引入了具有铜和钴活性位点的双金属共价有机框架催化剂,以实现两步串联反应,避免亚硝酸盐过度积累并实现高效NORR。对于初始的两电子过程,双金属催化剂中的铜位点与硝酸盐表现出很强的结合亲和力,促进其转化为亚硝酸盐。钴位点增强了活性氢的供应和吸附,并稳定了随后的六电子过程,从而提高了整体催化效率。与单金属铜和钴催化剂相比,CuCo双金属催化剂表现出更高的氨产率和法拉第效率(在0.3 M硝酸盐中,氨产率 = 20.8 mg·h·cm,FE = 92.16%)。这种协同的两步过程通过优化级联催化反应提高了NORR的效率和适用性,从而为NORR电催化剂的工程设计开辟了一条创新途径。
