The plasma process is often used in the fabrication of semiconductor wafers. However, due to the lack of real-time etching control, this may result in some unacceptable process performances and thus leads to significant waste and lower wafer yield. In order to maximize the product wafer yield, a timely and accurately process fault or abnormal detection in a plasma reactor is needed. Optical emission spectroscopy (OES) is one of the most frequently used metrologies in in-situ process monitoring. Even though OES has the advantage of non-invasiveness, it is required to provide a huge amount of information. As a result, the data analysis of OES becomes a big challenge. To accomplish real-time detection, this work employed the sigma matching method technique, which is the time series of OES full spectrum intensity. First, the response model of a healthy plasma spectrum was developed. Then, we defined a matching rate as an indictor for comparing the difference between the tested wafers response and the health sigma model. The experimental results showed that this proposal method can detect process faults in real-time, even in plasma etching tools.
等离子体工艺常用于半导体晶圆的制造。然而,由于缺乏实时刻蚀控制,这可能导致一些不可接受的工艺性能,从而导致大量浪费和晶圆产量降低。为了最大限度地提高产品晶圆的产量,需要及时准确地检测等离子体反应器中的工艺故障或异常。光学发射光谱 (OES) 是原位过程监测中最常用的计量技术之一。尽管 OES 具有非侵入性的优点,但它需要提供大量的信息。因此,OES 的数据分析成为一个巨大的挑战。为了实现实时检测,这项工作采用了 sigma 匹配方法技术,即 OES 全光谱强度的时间序列。首先,开发了健康等离子体光谱的响应模型。然后,我们定义了一个匹配率作为指标,用于比较测试晶圆的响应与健康 sigma 模型之间的差异。实验结果表明,该方法即使在等离子体刻蚀工具中也可以实时检测工艺故障。
