Shon Won Yong, Sharma Vivek, Keon Oh Jong, Moon Jun Gyu, Suh Dong Hun
Department of Orthopedics Surgery, Korea University, Guro Hospital, Seoul, South Korea.
Department of Orthopedics Surgery, Korea University, Guro Hospital, Seoul, South Korea.
Int J Surg Case Rep. 2014;5(9):633-6. doi: 10.1016/j.ijscr.2014.07.015. Epub 2014 Jul 24.
The orientation of acetabular component is influenced by pelvic tilt, body position and individual variation in pelvic parameters. Most post-operative adverse events may be attributed to malposition of the component in the functional position. There is evidence that orientation of the pelvis changes from the supine to standing position. Authors report a case of recurrent dislocation after total hip arthroplasty due to excessive pelvic tilting. PRESENTATION OF CASE A 69-year old female with coxarthrosis had undergone total hip replacement with recurrent dislocation of the hip on bearing weight in spite of using constrained acetabular component.
Our case report substantiates the influence of pelvic tilt, incurred by a sagittal deformity of spine, on dynamic orientation of the acetabular cup which was positioned in accordance with the anatomic landmarks alone. If the reference is only bony architecture and dynamic positions of the pelvis are not taken into account, improper functional orientation of the acetabular cup can result in sitting and standing positions. These can induce instability even in anatomically appropriately oriented acetabular component.
The sagittal position of pelvis is a key factor in impingement and dislocation after total hip arthroplasty. Pelvic tilting affects the position of acetabular component in the sagittal plane of the body as compared with its anatomic position in the pelvis. We suggest a preoperative lateral view of spine-pelvis, in upright and supine position for evaluation of a corrective adaptation of the acetabular cup accordingly with pelvic balance.
髋臼假体的方向受骨盆倾斜、身体位置及骨盆参数个体差异的影响。大多数术后不良事件可能归因于假体在功能位置的放置不当。有证据表明,骨盆方向从仰卧位到站立位会发生变化。作者报告了一例因骨盆过度倾斜导致全髋关节置换术后复发性脱位的病例。
一名69岁患有髋关节炎的女性接受了全髋关节置换术,尽管使用了限制性髋臼假体,但在负重时仍出现髋关节复发性脱位。
我们的病例报告证实了脊柱矢状面畸形引起的骨盆倾斜对仅根据解剖标志定位的髋臼杯动态方向的影响。如果仅以骨骼结构为参考而不考虑骨盆的动态位置,髋臼杯功能方向不当会导致坐姿和站姿问题。即使髋臼假体在解剖学上方向正确,这些情况也会导致不稳定。
骨盆的矢状位是全髋关节置换术后撞击和脱位的关键因素。与髋臼假体在骨盆中的解剖位置相比,骨盆倾斜会影响其在身体矢状面的位置。我们建议术前拍摄脊柱-骨盆的侧位片,包括直立位和仰卧位,以评估髋臼杯根据骨盆平衡进行的矫正适应性。
