Ye Hui, Curcuru Austen
Department of Biology, Loyola University Chicago, 1032 W. Sheridan Rd, Chicago, IL 60660 USA.
Departments of Physics, Loyola University Chicago, 1032 W. Sheridan Rd, Chicago, IL 60660 USA.
BMC Biophys. 2015 Jan 21;8(1):2. doi: 10.1186/s13628-014-0016-0. eCollection 2015.
BACKGROUND: Cells exhibit distortion when exposed to a strong electric field, suggesting that the field imposes control over cellular biomechanics. Closed pure lipid bilayer membranes (vesicles) have been widely used for the experimental and theoretical studies of cellular biomechanics under this electrodeformation. An alternative method used to generate an electric field is by electromagnetic induction with a time-varying magnetic field. References reporting the magnetic control of cellular mechanics have recently emerged. However, theoretical analysis of the cellular mechanics under a time-varying magnetic field is inadequate. We developed an analytical theory to investigate the biomechanics of a modeled vesicle under a time-varying magnetic field. Following previous publications and to simplify the calculation, this model treated the inner and suspending media as lossy dielectrics, the membrane thickness set at zero, and the electric resistance of the membrane assumed to be negligible. This work provided the first analytical solutions for the surface charges, electric field, radial pressure, overall translational forces, and rotational torques introduced on a vesicle by the time-varying magnetic field. Frequency responses of these measures were analyzed, particularly the frequency used clinically by transcranial magnetic stimulation (TMS). RESULTS: The induced surface charges interacted with the electric field to produce a biomechanical impact upon the vesicle. The distribution of the induced surface charges depended on the orientation of the coil and field frequency. The densities of these charges were trivial at low frequency ranges, but significant at high frequency ranges. The direction of the radial force on the vesicle was dependent on the conductivity ratio between the vesicle and the medium. At relatively low frequencies (<200 KHz), including the frequency used in TMS, the computed radial pressure and translational forces on the vesicle were both negligible. CONCLUSIONS: This work provides an analytical framework and insight into factors affecting cellular biomechanics under a time-varying magnetic field. Biological effects of clinical TMS are not likely to occur via alteration of the biomechanics of brain cells.
背景:细胞在暴露于强电场时会表现出变形,这表明电场对细胞生物力学具有控制作用。封闭的纯脂质双分子层膜(囊泡)已被广泛用于在此种电形成作用下对细胞生物力学的实验和理论研究。另一种用于产生电场的方法是通过随时间变化的磁场进行电磁感应。最近出现了关于细胞力学磁控的参考文献报道。然而,对随时间变化磁场下细胞力学的理论分析还不够充分。我们开发了一种分析理论来研究随时间变化磁场下模拟囊泡的生物力学。遵循先前的出版物并为简化计算,该模型将内部和悬浮介质视为有损电介质,将膜厚度设为零,并假定膜的电阻可忽略不计。这项工作提供了随时间变化磁场在囊泡上引入的表面电荷、电场、径向压力、整体平移力和旋转扭矩的首个解析解。分析了这些量度的频率响应,特别是经颅磁刺激(TMS)在临床上使用的频率。 结果:感应表面电荷与电场相互作用,对囊泡产生生物力学影响。感应表面电荷的分布取决于线圈的方向和场频率。这些电荷的密度在低频范围内微不足道,但在高频范围内显著。囊泡上径向力的方向取决于囊泡与介质之间的电导率比。在相对低频(<200千赫兹),包括TMS中使用的频率,计算得出的囊泡径向压力和平移力都可忽略不计。 结论:这项工作提供了一个分析框架,并深入了解了影响随时间变化磁场下细胞生物力学的因素。临床TMS的生物学效应不太可能通过改变脑细胞的生物力学而发生。
