Su Jiqing, Chen Wen, Yang Huiyun, Hong Jidong, Zhang Zijian, Yang Guangzheng, Li Li, Wei Rui
Department of Oncology, Changsha Central Hospital, Changsha, People's Republic of China ; Department of Oncology, Xiangya Hospital, Central South University, Changsha, People's Republic of China.
Department of Oncology, Xiangya Hospital, Central South University, Changsha, People's Republic of China.
Onco Targets Ther. 2015 Sep 14;8:2545-53. doi: 10.2147/OTT.S87159. eCollection 2015.
The study aimed to investigate the difference of setup errors on different registration in the treatment of nasopharyngeal carcinoma based on weekly cone-beam computed tomography (CBCT). Thirty nasopharyngeal cancer patients scheduled to undergo intensity-modulated radiotherapy (IMRT) were prospectively enrolled in the study. Each patient had a weekly CBCT before radiation therapy. In the entire study, 201 CBCT scans were obtained. The scans were registered to the planning CT to determine the difference of setup errors on different registration sites. Different registration sites were represented by bony landmarks. Nasal septum and pterygoid process represent head, cervical vertebrae 1-3 represent upper neck, and cervical vertebrae 4-6 represent lower neck. Patient positioning errors were recorded in the right-left (RL), superior-inferior (SI), and anterior-posterior (AP) directions over the course of radiotherapy. Planning target volume margins were calculated from the systematic and random errors. In this study, we can make a conclusion that there are setup errors in RL, SI, and AP directions of nasopharyngeal carcinoma patients undergoing IMRT. In addition, the head and neck setup error has the difference, with statistical significance, while patient setup error of neck is greater than that of head during the course of radiotherapy. In our institution, we recommend a planning target volume margin of 3.0 mm in RL direction, 1.3 mm in SI direction, and 2.6 mm in AP direction for nasopharyngeal cancer patients undergoing IMRT with weekly CBCT scans.
本研究旨在基于每周一次的锥形束计算机断层扫描(CBCT),调查鼻咽癌治疗中不同配准方式下的摆位误差差异。前瞻性纳入30例计划接受调强放射治疗(IMRT)的鼻咽癌患者。每位患者在放疗前每周进行一次CBCT扫描。在整个研究过程中,共获得201次CBCT扫描。将扫描图像与计划CT进行配准,以确定不同配准部位的摆位误差差异。不同的配准部位由骨性标志表示。鼻中隔和翼突代表头部,第1 - 3颈椎代表上颈部,第4 - 6颈椎代表下颈部。在放疗过程中记录患者在左右(RL)、上下(SI)和前后(AP)方向的摆位误差。根据系统误差和随机误差计算计划靶区边缘。在本研究中,我们可以得出结论,接受IMRT的鼻咽癌患者在RL、SI和AP方向存在摆位误差。此外,头颈部的摆位误差存在差异,具有统计学意义,且在放疗过程中颈部的患者摆位误差大于头部。在我们机构,对于每周进行CBCT扫描的接受IMRT的鼻咽癌患者,我们建议在RL方向的计划靶区边缘为3.0 mm,SI方向为1.3 mm,AP方向为2.6 mm。
