gtrellis: an R/Bioconductor package for making genome-level Trellis graphics.

BACKGROUND

Trellis graphics are a visualization method that splits data by one or more categorical variables and displays subsets of the data in a grid of panels. Trellis graphics are broadly used in genomic data analysis to compare statistics over different categories in parallel and reveal multivariate relationships. However, current software packages to produce Trellis graphics have not been designed with genomic data in mind and lack some functionality that is required for effective visualization of genomic data.

RESULTS

Here we introduce the gtrellis package which provides an efficient and extensible way to visualize genomic data in a Trellis layout. gtrellis provides highly flexible Trellis layouts which allow efficient arrangement of genomic categories on the plot. It supports multiple-track visualization, which makes it straightforward to visualize several properties of genomic data in parallel to explain complex relationships. In addition, gtrellis provides an extensible framework that allows adding user-defined graphics.

CONCLUSIONS

The gtrellis package provides an easy and effective way to visualize genomic data and reveal high dimensional relationships on a genome-wide scale. gtrellis can be flexibly extended and thus can also serve as a base package for highly specific purposes. gtrellis makes it easy to produce novel visualizations, which can lead to the discovery of previously unrecognized patterns in genomic data.
