具有超小尺寸和增强上转换发光性能的单分散六方相 NaYF₄:Yb/Er 纳米晶的控制合成。

Controlled Synthesis of Monodisperse Hexagonal NaYF₄:Yb/Er Nanocrystals with Ultrasmall Size and Enhanced Upconversion Luminescence.

机构信息

MIIT Key Laboratory of Critical Materials Technology for New Energy Conversion and Storage, School of Chemistry and Chemical Engineering & Key Laboratory of Micro-Systems and Micro-Structures, Ministry of Education, Harbin Institute of Technology, Harbin 150001, China.

出版信息

Molecules. 2017 Dec 1;22(12):2113. doi: 10.3390/molecules22122113.

Abstract

The ability to synthesize upconversion nanocrystals (UCNCs) with tailored upconversion luminescence and controlled size is of great importance for biophotonic applications. However, until now, limited success has been met to prepare bright, ultrasmall, and monodispersed β-NaYF₄:Yb/Er UCNCs. In this work, we report on a synthetic method to produce monodisperse hexagonal NaYF₄:Yb/Er nanocrystals of ultrasmall size (5.4 nm) through a precise control of the reaction temperature and the ratio of Na⁺/Ln/F. We determined the optimum activator concentration of Er to be 6.5 mol % for these UCNCs, yielding about a 5-fold higher upconversion luminescence (UCL) intensity than the commonly used formula of NaYF₄:30% Yb/2% Er. Moreover, a thin epitaxial shell (thickness, 1.9 nm) of NaLnF₄ (Ln = Y, Gd, Lu) was grown onto these ultrasmall NaYF₄:Yb/Er NCs, enhancing its UCL by about 85-, 70- and 50-fold, respectively. The achieved sub-10-nm core and core-shell hexagonal NaYF₄:Yb/Er UCNCs with enhanced UCL have strong potential applications in bioapplications such as bioimaging and biosensing.

摘要

合成具有可调上转换发光和受控尺寸的上转换纳米晶体 (UCNCs) 对于生物光子学应用非常重要。然而,迄今为止,在制备亮、超小和单分散β-NaYF₄:Yb/Er UCNCs 方面,取得的成功有限。在这项工作中,我们报告了一种通过精确控制反应温度和 Na⁺/Ln/F 比来制备单分散六方 NaYF₄:Yb/Er 纳米晶体的合成方法,这些纳米晶体的尺寸非常小(5.4nm)。我们确定了这些 UCNCs 中 Er 的最佳激活剂浓度为 6.5mol%,与常用的 NaYF₄:30%Yb/2%Er 相比,上转换发光(UCL)强度提高了约 5 倍。此外,在这些超小的 NaYF₄:Yb/Er NCs 上生长了一层厚度为 1.9nm 的薄外延壳(Ln = Y、Gd、Lu),分别将其 UCL 增强了约 85、70 和 50 倍。实现的亚 10nm 核和核壳六方 NaYF₄:Yb/Er UCNCs 具有增强的 UCL,在生物成像和生物传感等生物应用中具有很强的应用潜力。
