年龄和性别对腰椎椎管和神经孔狭窄的分布和对称性的影响:43255 份腰椎 MRI 报告的自然语言处理分析。

Effects of age and sex on the distribution and symmetry of lumbar spinal and neural foraminal stenosis: a natural language processing analysis of 43,255 lumbar MRI reports.

机构信息

Brigham and Women's Hospital and Harvard Medical School, Boston, MA, USA.

University of California San Francisco, 505 Parnassus Avenue, L352, CA, 94117, San Francisco, USA.

出版信息

Neuroradiology. 2021 Jun;63(6):959-966. doi: 10.1007/s00234-021-02670-6. Epub 2021 Feb 16.


DOI:10.1007/s00234-021-02670-6
PMID:33594502
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC8128837/
Abstract

PURPOSE: The purpose of this study is to investigate relationship of patient age and sex to patterns of degenerative spinal stenosis on lumbar MRI (LMRI), rated as moderate or greater by a spine radiologist, using natural language processing (NLP) tools. METHODS: In this retrospective, IRB-approved study, LMRI reports acquired from 2007 to 2017 at a single institution were parsed with a rules-based natural language processing (NLP) algorithm for free-text descriptors of spinal canal stenosis (SCS) and neural foraminal stenosis (NFS) at each of six spinal levels (T12-S1) and categorized according to a 6-point grading scale. Demographic differences in the anatomic distribution of moderate (grade 3) or greater SCS and NFS were calculated by sex, and age and within-group differences for NFS symmetry (left vs. right) were calculated as odds ratios. RESULTS: Forty-three thousand two hundred fifty-five LMRI reports (34,947 unique patients, mean age = 54.7; sex = 54.9% women) interpreted by 152 radiologists were studied. Prevalence of significant SCS and NFS increased caudally from T12-L1 to L4-5 though less at L5-S1. NFS was asymmetrically more prevalent on the left at L2-L3 and L5-S1 (p < 0.001). SCS and NFS were more prevalent in men and SCS increased with age at all levels, but the effect size of age was largest at T12-L3. Younger patients (< 50 years) had relatively higher NFS prevalence at L5-S1. CONCLUSION: NLP can identify patterns of lumbar spine degeneration through analysis of a large corpus of radiologist interpretations. Demographic differences in stenosis prevalence shed light on the natural history and pathogenesis of LSDD.

摘要

目的:本研究旨在通过自然语言处理(NLP)工具,调查腰椎 MRI(LMRI)上退行性脊柱狭窄的模式与患者年龄和性别之间的关系,这些模式由脊柱放射科医生评定为中度或更严重。

方法:在这项回顾性、IRB 批准的研究中,对单家机构在 2007 年至 2017 年期间获得的 LMRI 报告进行了分析,使用基于规则的自然语言处理(NLP)算法对椎管狭窄(SCS)和神经孔狭窄(NFS)的自由文本描述进行解析,共分析了六个脊柱水平(T12-S1)的每个水平,并按照六级分级量表进行分类。根据性别计算了中度(3 级)或更严重 SCS 和 NFS 的解剖分布的性别差异,并计算了 NFS 对称性(左侧与右侧)的年龄内差异,以比值比表示。

结果:研究共分析了 43255 份 LMRI 报告(34947 名患者,平均年龄为 54.7 岁,54.9%为女性),由 152 名放射科医生进行解读。从 T12-L1 到 L4-5,SCS 和 NFS 的发生率逐渐增加,但在 L5-S1 处减少。在 L2-L3 和 L5-S1 处,NFS 左侧不对称性更为常见(p<0.001)。SCS 和 NFS 在男性中更为常见,且 SCS 在所有水平上均随年龄增长而增加,但年龄的效应大小在 T12-L3 最大。年轻患者(<50 岁)在 L5-S1 处 NFS 的患病率相对较高。

结论:通过对大量放射科医生解读的分析,NLP 可以识别腰椎退变的模式。狭窄发生率的人口统计学差异为 LSDD 的自然史和发病机制提供了线索。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/c78c7dcee39d/234_2021_2670_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/dc44a2275e84/234_2021_2670_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/f53d425ff0c0/234_2021_2670_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/51c0c314aee4/234_2021_2670_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/378e76c10d17/234_2021_2670_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/c78c7dcee39d/234_2021_2670_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/dc44a2275e84/234_2021_2670_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/f53d425ff0c0/234_2021_2670_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/51c0c314aee4/234_2021_2670_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/378e76c10d17/234_2021_2670_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6519/8128837/c78c7dcee39d/234_2021_2670_Fig5_HTML.jpg
