Zhai Yuan, Xiang Yi, Yuan Weiqing, Chen Gang, Shi Jinliang, Liang Gaofeng, Wen Zhongquan, Wu Ying
Intelligent Technology and Engineering, Chongqing University of Science and Technology, Chongqing 401331, China.
College of Optoelectronic Engineering, Chongqing University, Chongqing 400044, China.
Micromachines (Basel). 2021 May 31;12(6):641. doi: 10.3390/mi12060641.
High sensitivity detection of terahertz waves can be achieved with a graphene nanomesh as grating to improve the coupling efficiency of the incident terahertz waves and using a graphene nanostructure energy gap to enhance the excitation of plasmon. Herein, the fabrication process of the FET THz detector based on the rectangular GNM (r-GNM) is designed, and the THz detector is developed, including the CVD growth and the wet-process transfer of high quality monolayer graphene films, preparation of r-GNM by electron-beam lithography and oxygen plasma etching, and the fabrication of the gate electrodes on the SiN dielectric layer. The problem that the conductive metal is easy to peel off during the fabrication process of the GNM THz device is mainly discussed. The photoelectric performance of the detector was tested at room temperature. The experimental results show that the sensitivity of the detector is 2.5 A/W (@ 3 THz) at room temperature.
以石墨烯纳米网作为光栅,可实现太赫兹波的高灵敏度检测,以提高入射太赫兹波的耦合效率,并利用石墨烯纳米结构的能隙增强表面等离子体激元的激发。在此,设计了基于矩形石墨烯纳米网(r-GNM)的场效应晶体管太赫兹探测器的制造工艺,并开发了太赫兹探测器,包括高质量单层石墨烯薄膜的化学气相沉积生长和湿法转移、通过电子束光刻和氧等离子体蚀刻制备r-GNM,以及在氮化硅介电层上制造栅电极。主要讨论了在GNM太赫兹器件制造过程中导电金属容易剥离的问题。在室温下测试了探测器的光电性能。实验结果表明,该探测器在室温下的灵敏度为2.5 A/W(@ 3太赫兹)。
