van Huizen Laura M G, Radonic Teodora, van Mourik Frank, Seinstra Danielle, Dickhoff Chris, Daniels Johannes M A, Bahce Idris, Annema Jouke T, Groot Marie Louise
Faculty of Science, Department of Physics, LaserLab Vrije Universiteit Amsterdam Amsterdam Netherlands.
Department of Pathology Amsterdam Universities Medical Center/VU University Medical Center Amsterdam Netherlands.
Transl Biophotonics. 2020 Nov;2(4):e202000009. doi: 10.1002/tbio.202000009. Epub 2020 Aug 21.
During lung cancer operations a rapid and reliable assessment of tumor tissue can reduce operation time and potentially improve patient outcomes. We show that third harmonic generation (THG), second harmonic generation (SHG) and two-photon excited autofluorescence (2PEF) microscopy reveals relevant, histopathological information within seconds in fresh unprocessed human lung samples. We used a compact, portable microscope and recorded images within 1 to 3 seconds using a power of 5 mW. The generated THG/SHG/2PEF images of tumorous and nontumorous tissues are compared with the corresponding standard histology images, to identify alveolar structures and histopathological hallmarks. Cellular structures (tumor cells, macrophages and lymphocytes) (THG), collagen (SHG) and elastin (2PEF) are differentiated and allowed for rapid identification of carcinoid with solid growth pattern, minimally enlarged monomorphic cell nuclei with salt-and-pepper chromatin pattern, and adenocarcinoma with lipidic and micropapillary growth patterns. THG/SHG/2PEF imaging is thus a promising tool for clinical intraoperative assessment of lung tumor tissue.
在肺癌手术过程中,对肿瘤组织进行快速可靠的评估可以缩短手术时间,并有可能改善患者的预后。我们发现,三次谐波产生(THG)、二次谐波产生(SHG)和双光子激发自发荧光(2PEF)显微镜能够在数秒内揭示新鲜未处理的人类肺样本中的相关组织病理学信息。我们使用了一台紧凑的便携式显微镜,以5毫瓦的功率在1至3秒内记录图像。将生成的肿瘤组织和非肿瘤组织的THG/SHG/2PEF图像与相应的标准组织学图像进行比较,以识别肺泡结构和组织病理学特征。细胞结构(肿瘤细胞、巨噬细胞和淋巴细胞)(THG)、胶原蛋白(SHG)和弹性蛋白(2PEF)得以区分,从而能够快速识别具有实性生长模式的类癌、具有椒盐染色质模式的轻度增大的单形细胞核,以及具有脂质和微乳头生长模式的腺癌。因此,THG/SHG/2PEF成像对于肺肿瘤组织的临床术中评估是一种很有前景的工具。
