Volumetric Changes of a Customized Allogeneic Bone Block Measured by Two Image Matching Tools: Introduction of a Novel Assessment Technique for Graft Resorption.

OBJECTIVE

The purpose of this case report was to present a method for the assessment of volumetric changes of bone blocks during healing and demonstrate its practicability by analysing the resorption of a pre-shaped allogeneic bone block used for the reconstruction of a complex maxillary defect.

MATERIALS AND METHODS

CBCT-scans of a 19-year-old male treated with an allogeneic bone block were recorded pre-OP, post-OP, and following six months of healing. Graft shrinkage was assessed via two image matching tools, namely coDiagnostiX® and Slicer. A biopsy specimen was harvested along the implant canal at the time of implantation.

RESULTS

The osseous defect was successfully restored and advanced graft remodelling was found upon re-entry as confirmed by the histomorphometric and histologic analysis. The initial volumes of the graft determined via coDiagnostiX® and Slicer were 0.373 mL and 0.370 mL., respectively, while graft resorption after six months of healing was 0.011 mL (3.00%) and 0.016 mL (4.33%).

CONCLUSIONS

The avoidance of bone harvesting and reduction of invasiveness display an important issue in dentoalveolar restorations. However, before grafting materials can be considered a safe alternative, understanding their clinical performance, especially resorption stability, is pivotal. The present case report demonstrates a limited resorption of the allogeneic bone block and further emphasizes the practicability of determining bone resorption by the here introduced method. As our investigation comprises solely one subject, the results should be considered with care and substantiated by further studies.
