Research on Multiple Spectral Ranges with Deep Learning for SpO Measurement.

Oxyhemoglobin saturation by pulse oximetry (SpO) has always played an important role in the diagnosis of symptoms. Considering that the traditional SpO measurement has a certain error due to the number of wavelengths and the algorithm and the wider application of machine learning and spectrum combination, we propose to use 12-wavelength spectral absorption measurement to improve the accuracy of SpO measurement. To investigate the multiple spectral regions for deep learning for SpO measurement, three datasets for training and verification were built, which were constructed over the spectra of first region, second region, and full region and their sub-regions, respectively. For each region under the procedures of optimization of our model, a thorough of investigation of hyperparameters is proceeded. Additionally, data augmentation is preformed to expand dataset with added noise randomly, increasing the diversity of data and improving the generalization of the neural network. After that, the established dataset is input to a one dimensional convolution neural network (1D-CNN) to obtain a measurement model of SpO. In order to enhance the model accuracy, GridSearchCV and Bayesian optimization are applied to optimize the hyperparameters. The optimal accuracies of proposed model optimized by GridSearchCV and Bayesian Optimization is 89.3% and 99.4%, respectively, and trained with the dataset at the spectral region of six wavelengths including 650 nm, 680 nm, 730 nm, 760 nm, 810 nm, 860 nm. The total relative error of the best model is only 0.46%, optimized by Bayesian optimization. Although the spectral measurement with more features can improve the resolution ability of the neural network, the results reveal that the training with the dataset of the shorter six wavelength is redundant. This analysis shows that it is very important to construct an effective 1D-CNN model area for spectral measurement using the appropriate spectral ranges and number of wavelengths. It shows that our proposed 1D-CNN model gives a new and feasible approach to measure SpO based on multi-wavelength.
