Zhong Minghao, Yang Zhiqi, Chen Xiaofeng, Huang Ruibin, Wang Mengzhu, Fan Weixiong, Dai Zhuozhi, Chen Xiangguang
Department of Radiology, Meizhou People's Hospital, Meizhou, 514031, China.
Guangdong Provincial Key Laboratory of Precision Medicine and Clinical Translational Research of Hakka Population, Meizhou, 514031, China.
J Magn Reson Imaging. 2022 Sep;56(3):691-699. doi: 10.1002/jmri.28065. Epub 2022 Jan 17.
Readout-segmented echo-planar diffusion-weighted imaging (RS-EPI) can improve image quality and signal-to-noise ratio, the resulting apparent diffusion coefficient (ADC) value acts as a more sensitive biomarker to characterize tumors. However, data regarding the differentiation of breast cancer (BC) receptor statuses using RS-EPI are limited.
To determine whether RS-EPI improves the differentiation of receptor statuses compared with conventional single-shot (SS) EPI in breast MRI.
Retrospective.
A total of 151 BC women with the mean age of 50.6 years.
FIELD STRENGTH/SEQUENCE: A 3 T/ RS-EPI and SS-EPI.
The ADCs of the lesion and normal background tissue from the two sequences were collected by two radiologists with 15 years of experience working of breast MRI (M.H.Z. and X.F.C.), and a normalized ADC was calculated by dividing the mean ADC value of the lesion by the mean ADC value of the normal background tissue.
Agreement between the ADC measurements from the two sequences was assessed using the Pearson correlation coefficient and Bland-Altman plots. One-way analysis of variance, Kruskal-Wallis test, and median difference were used to compare the ADC measurements for all lesions and different receptor statuses. A P value less than 0.05 indicated a significant result.
The ADC measurements of all lesions and normal background tissues were significantly higher on RS-EPI than on SS-EPI (1.82 ± 0.33 vs. 1.55 ± 0.30 and 0.83 ± 0.11 vs. 0.79 ± 0.10). The normalized ADC was lower on RS-EPI than on SS-EPI (0.47 ± 0.11 vs. 0.53 ± 0.12, a median difference of -0.04 [95% CI: -0.256 to 0.111]). For both diffusion methods, only the ADC measurement of RS-EPI was higher for human epidermal growth factor receptor-2 (HER-2)-positive tumors than for HER-2-negative tumors (0.87 ± 0.10 vs. 0.81 ± 0.11), and this measurement was associated with HER-2 positive status (adjusted odds ratio [OR] = 654.4); however, similar results were not observed for the ADC measurement of SS-EPI (0.80 ± 0.10 vs. 0.78 ± 0.11 with P = 0.199 and adjusted OR = 0.21 with P = 0.464, respectively).
RS-EPI can improve the distinction between HER-2-positive and HER-2-negative breast cancer, complementing the clinical application of diffusion imaging.
3 TECHNICAL EFFICACY: Stage 1.
读出分段回波平面扩散加权成像(RS-EPI)可改善图像质量和信噪比,由此得到的表观扩散系数(ADC)值可作为一种更敏感的生物标志物用于肿瘤特征描述。然而,关于利用RS-EPI鉴别乳腺癌(BC)受体状态的数据有限。
确定在乳腺磁共振成像(MRI)中,与传统单次激发(SS)EPI相比,RS-EPI是否能改善受体状态的鉴别。
回顾性研究。
共151例BC女性,平均年龄50.6岁。
场强/序列:3T/RS-EPI和SS-EPI。
由两位具有15年乳腺MRI工作经验的放射科医生(M.H.Z.和X.F.C.)收集两个序列中病变及正常背景组织的ADC值,并通过将病变的平均ADC值除以正常背景组织的平均ADC值来计算标准化ADC。
使用Pearson相关系数和Bland-Altman图评估两个序列ADC测量值之间的一致性。采用单因素方差分析、Kruskal-Wallis检验和中位数差异来比较所有病变及不同受体状态的ADC测量值。P值小于0.05表示结果具有显著性。
所有病变及正常背景组织的ADC测量值在RS-EPI上均显著高于SS-EPI(分别为1.82±0.33与1.55±0.30以及0.83±0.11与0.79±0.10)。标准化ADC在RS-EPI上低于SS-EPI(0.47±0.11与0.53±0.12,中位数差异为-0.04[95%CI:-0.256至0.111])。对于两种扩散方法,仅RS-EPI的ADC测量值在人表皮生长因子受体2(HER-2)阳性肿瘤中高于HER-2阴性肿瘤(0.87±0.10与0.
