使用热成像进行非接触式应激分类。

Towards a Contactless Stress Classification Using Thermal Imaging.

机构信息

Dipartimento di Ingegneria dell'Informazione, University of Pisa, 56122 Pisa, Italy.

Research Center "E. Piaggio", University of Pisa, 56122 Pisa, Italy.

出版信息

Sensors (Basel). 2022 Jan 27;22(3):976. doi: 10.3390/s22030976.


DOI:10.3390/s22030976
PMID:35161722
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC8839779/
Abstract

Thermal cameras capture the infrared radiation emitted from a body in a contactless manner and can provide an indirect estimation of the autonomic nervous system (ANS) dynamics through the regulation of the skin temperature. This study investigates the contribution given by thermal imaging for an effective automatic stress detection with the perspective of a contactless stress recognition system. To this aim, we recorded both ANS correlates (cardiac, electrodermal, and respiratory activity) and thermal images from 25 volunteers under acute stress induced by the Stroop test. We conducted a statistical analysis on the features extracted from each signal, and we implemented subject-independent classifications based on the support vector machine model with an embedded recursive feature elimination algorithm. Particularly, we trained three classifiers using different feature sets: the full set of features, only those derived from the peripheral autonomic correlates, and only those derived from the thermal images. Classification accuracy and feature selection results confirmed the relevant contribution provided by the thermal features in the acute stress detection task. Indeed, a combination of ANS correlates and thermal features achieved 97.37% of accuracy. Moreover, using only thermal features we could still successfully detect stress with an accuracy of 86.84% in a contact-free manner.

摘要

热像仪以非接触的方式捕捉人体发出的红外辐射,并可以通过调节皮肤温度来提供自主神经系统 (ANS) 动态的间接估计。本研究通过接触式应激识别系统的角度,探讨了热成像在有效自动应激检测中的作用。为此,我们记录了 25 名志愿者在斯特鲁普测试诱发的急性应激下的 ANS 相关指标(心率变异性、皮肤电反应和呼吸活动)和热像图。我们对每个信号提取的特征进行了统计分析,并基于支持向量机模型和嵌入式递归特征消除算法实现了基于个体的分类。具体来说,我们使用不同的特征集训练了三个分类器:完整的特征集、仅来自外周自主相关的特征集,以及仅来自热像图的特征集。分类准确性和特征选择结果证实了热特征在急性应激检测任务中的重要贡献。事实上,将自主神经相关指标和热特征相结合,可以达到 97.37%的准确率。此外,仅使用热特征,我们仍然可以以非接触的方式成功地以 86.84%的准确率检测到应激。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/e9fbb1643856/sensors-22-00976-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/9bc9c3458904/sensors-22-00976-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/52ed05f529d3/sensors-22-00976-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/62a36431cd24/sensors-22-00976-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/715274445b0f/sensors-22-00976-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/ace6157377e9/sensors-22-00976-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/eb7a7501b44b/sensors-22-00976-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/dd1fdc3734e7/sensors-22-00976-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/629422a63712/sensors-22-00976-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/e9fbb1643856/sensors-22-00976-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/9bc9c3458904/sensors-22-00976-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/52ed05f529d3/sensors-22-00976-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/62a36431cd24/sensors-22-00976-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/715274445b0f/sensors-22-00976-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/ace6157377e9/sensors-22-00976-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/eb7a7501b44b/sensors-22-00976-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/dd1fdc3734e7/sensors-22-00976-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/629422a63712/sensors-22-00976-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f89/8839779/e9fbb1643856/sensors-22-00976-g009.jpg
