Tamagawa Shota, Sakai Daisuke, Nojiri Hidetoshi, Sato Masato, Ishijima Muneaki, Watanabe Masahiko
Department of Medicine for Orthopaedics and Motor Organ, Juntendo University Graduate School of Medicine, 2-1-1 Hongo, Bunkyo-Ku, Tokyo 113-8421, Japan.
Department of Orthopaedic Surgery, Surgical Science, Tokai University School of Medicine, 143 Shimokasuya, Isehara 259-1193, Kanagawa, Japan.
Diagnostics (Basel). 2022 Mar 14;12(3):707. doi: 10.3390/diagnostics12030707.
In recent years, various quantitative and functional magnetic resonance imaging (MRI) sequences have been developed and used in clinical practice for the diagnosis of patients with low back pain (LBP). Until now, T2-weighted imaging (T2WI), a visual qualitative evaluation method, has been used to diagnose intervertebral disc (IVD) degeneration. However, this method has limitations in terms of reproducibility and inter-observer agreement. Moreover, T2WI observations do not directly relate with LBP. Therefore, new sequences such as T2 mapping, T1ρ mapping, and MR spectroscopy have been developed as alternative quantitative evaluation methods. These new quantitative MRIs can evaluate the anatomical and physiological changes of IVD degeneration in more detail than conventional T2WI. However, the values obtained from these quantitative MRIs still do not directly correlate with LBP, and there is a need for more widespread use of techniques that are more specific to clinical symptoms such as pain. In this paper, we review the state-of-the-art methodologies and future challenges of quantitative MRI as an imaging diagnostic tool for IVD degeneration and painful discs.
近年来,各种定量和功能磁共振成像(MRI)序列已被开发并应用于临床实践,用于诊断腰痛(LBP)患者。到目前为止,T2加权成像(T2WI),一种视觉定性评估方法,一直被用于诊断椎间盘(IVD)退变。然而,该方法在可重复性和观察者间一致性方面存在局限性。此外,T2WI观察结果与LBP没有直接关联。因此,诸如T2映射、T1ρ映射和磁共振波谱等新序列已被开发出来作为替代的定量评估方法。这些新的定量MRI能够比传统T2WI更详细地评估IVD退变的解剖和生理变化。然而,从这些定量MRI获得的值仍然与LBP没有直接关联,并且需要更广泛地使用对诸如疼痛等临床症状更具特异性的技术。在本文中,我们综述了作为IVD退变和疼痛椎间盘成像诊断工具的定量MRI的最新方法和未来挑战。
