嵌入静电纺丝聚乙烯醇纳米纤维中的纳米氧化铈对稀土元素的回收

Recovery of rare earth elements by nanometric CeO embedded into electrospun PVA nanofibres.

作者信息

Comandella Daniele, Bonani Walter, Ciscar Jorge Bañuls, Ponti Jessica, Cologna Marco, Popa Karin, Gilliland Douglas

机构信息

European Commission, Joint Research Centre (JRC) Ispra Italy

European Commission, Joint Research Centre (JRC) Karlsruhe Germany.

出版信息

RSC Adv. 2021 May 28;11(32):19351-19362. doi: 10.1039/d1ra02097h. eCollection 2021 May 27.

Abstract

Rare earth elements (REEs) are critical raw materials with a wide range of industrial applications. As a result, the recovery of REEs adsorption from REE-rich matrices, such as water streams from processed electric and electronic waste, has gained increased attention for its simplicity, cost-effectiveness and high efficacy. In this work, the potential of nanometric cerium oxide-based materials as adsorbents for selected REEs is investigated. Ultra-small cerium oxide nanoparticles (CNPs, mean size diameter ≈ 3 nm) were produced a precipitation-hydrothermal procedure and incorporated into woven-non-woven polyvinyl alcohol (PVA) nanofibres ( ≈ 280 nm) electrospinning, to a final loading of ≈34 wt%. CNPs, CNP-PVA and the benchmark material CeO NM-212 (JRCNM02102, mean size diameter ≈ 28 nm) were tested as adsorbents for aqueous solutions of the REEs Eu, Gd and Yb at pH 5.8. Equilibrium adsorption data were interpreted by means of Langmuir and Freundlich data models. The maximum adsorption capacities ranged between 16 and 322 mg g , with the larger value found for the adsorption of Yb by CNP. The trend of maximum adsorption capacity was CNPs > NM-212 > CNP-PVA, which was ascribed to different agglomeration and surface area available for adsorption. Langmuir equilibrium constants were substantially larger for CNP-PVA, suggesting a potential higher affinity of REEs for CNPs due to a synergistic effect of PVA on adsorption. CNP-PVA were effectively used in repeated adsorption cycles under static and dynamic configurations and retained the vast majority of adsorptive material (>98% of CeO retained after 10 adsorption cycles). The small loss was attributed to partial solubilisation of fibre components with change in membrane morphology. The findings of this study pave the way for the application of CNP-PVA nanocomposites in the recovery of strategically important REEs from electrical and electronic waste.

摘要

稀土元素(REEs)是具有广泛工业应用的关键原材料。因此,从富含稀土元素的基体中回收稀土元素吸附物,如处理电子电气废弃物产生的水流中的吸附物,因其操作简单、成本效益高和效率高而受到越来越多的关注。在这项工作中,研究了基于纳米氧化铈的材料作为选定稀土元素吸附剂的潜力。通过沉淀 - 水热法制备了超小氧化铈纳米颗粒(CNPs,平均粒径约3 nm),并通过静电纺丝将其掺入机织 - 非织造聚乙烯醇(PVA)纳米纤维(约280 nm)中,最终负载量约为34 wt%。将CNPs、CNP - PVA和基准材料CeO NM - 212(JRCNM02102,平均粒径约28 nm)作为pH值为5.8的稀土元素铕(Eu)、钆(Gd)和镱(Yb)水溶液的吸附剂进行测试。利用朗缪尔(Langmuir)和弗伦德里希(Freundlich)数据模型解释平衡吸附数据。最大吸附容量在16至322 mg/g之间,其中CNP对Yb的吸附值最大。最大吸附容量的趋势为CNPs > NM - 212 > CNP - PVA,这归因于不同的团聚情况和可用于吸附的表面积。CNP - PVA的朗缪尔平衡常数显著更大,这表明由于PVA对吸附的协同作用,稀土元素对CNPs可能具有更高的亲和力。CNP - PVA在静态和动态配置下有效地用于重复吸附循环,并保留了绝大多数吸附材料(10次吸附循环后保留了>98%的CeO)。少量损失归因于随着膜形态变化纤维成分的部分溶解。本研究结果为CNP - PVA纳米复合材料在从电子电气废弃物中回收具有战略重要性的稀土元素方面的应用铺平了道路。
