Tickner Ben J, Zhivonitko Vladimir V
NMR Research Unit, Faculty of Science, University of Oulu P.O. Box 3000 Oulu 90014 Finland
Department of Chemical and Biological Physics, Faculty of Chemistry, Weizmann Institute of Science Rehovot 7610001 Israel.
Chem Sci. 2022 Mar 22;13(17):4670-4696. doi: 10.1039/d2sc00737a. eCollection 2022 May 4.
Parahydrogen-induced polarisation (PHIP) is a nuclear spin hyperpolarisation technique employed to enhance NMR signals for a wide range of molecules. This is achieved by exploiting the chemical reactions of parahydrogen (para-H), the spin-0 isomer of H. These reactions break the molecular symmetry of para-H in a way that can produce dramatically enhanced NMR signals for reaction products, and are usually catalysed by a transition metal complex. In this review, we discuss recent advances in novel homogeneous catalysts that can produce hyperpolarised products upon reaction with para-H. We also discuss hyperpolarisation attained in reversible reactions (termed signal amplification by reversible exchange, SABRE) and focus on catalyst developments in recent years that have allowed hyperpolarisation of a wider range of target molecules. In particular, recent examples of novel ruthenium catalysts for and hydrogenation, metal-free catalysts, iridium sulfoxide-containing SABRE systems, and cobalt complexes for PHIP and SABRE are reviewed. Advances in this catalysis have expanded the types of molecules amenable to hyperpolarisation using PHIP and SABRE, and their applications in NMR reaction monitoring, mechanistic elucidation, biomedical imaging, and many other areas, are increasing.
仲氢诱导极化(PHIP)是一种核自旋超极化技术,用于增强多种分子的核磁共振(NMR)信号。这是通过利用仲氢(para-H)(H的自旋为0的异构体)的化学反应来实现的。这些反应以一种能够显著增强反应产物NMR信号的方式打破了仲氢的分子对称性,并且通常由过渡金属配合物催化。在本综述中,我们讨论了新型均相催化剂的最新进展,这些催化剂在与仲氢反应时能够产生超极化产物。我们还讨论了在可逆反应中实现的超极化(称为可逆交换信号放大,SABRE),并重点关注近年来使更广泛范围的目标分子实现超极化的催化剂发展情况。特别是,综述了用于氢化反应的新型钌催化剂、无金属催化剂、含铱亚砜的SABRE体系以及用于PHIP和SABRE的钴配合物的近期实例。这种催化作用的进展扩大了使用PHIP和SABRE可实现超极化的分子类型,并且它们在NMR反应监测、机理阐明、生物医学成像以及许多其他领域的应用正在不断增加。
