Engineering Research Center of Molecular & Neuroimaging, Ministry of Education, School of Life Science and Technology, Xidian University, Xi'an, Shaanxi, 710126, China.
Academy of Advanced Interdisciplinary Research, Xidian University, Xi'an, Shaanxi, 710071, China.
Nat Commun. 2022 Jun 18;13(1):3513. doi: 10.1038/s41467-022-31136-3.
Advancement of bioorthogonal chemistry in molecular optical imaging lies in expanding the repertoire of fluorophores that can undergo fluorescence signal changes upon bioorthogonal ligation. However, most available bioorthogonally activatable fluorophores only emit shallow tissue-penetrating visible light via an intramolecular charge transfer mechanism. Herein, we report a serendipitous "torsion-induced disaggregation (TIDA)" phenomenon in the design of near-infrared (NIR) tetrazine (Tz)-based cyanine probe. The TIDA of the cyanine is triggered upon Tz-transcyclooctene ligation, converting its heptamethine chain from S-trans to S-cis conformation. Thus, after bioorthogonal reaction, the tendency of the resulting cyanine towards aggregation is reduced, leading to TIDA-induced fluorescence enhancement response. This Tz-cyanine probe sensitively delineates the tumor in living mice as early as 5 min post intravenous injection. As such, this work discovers a design mechanism for the construction of bioorthogonally activatable NIR fluorophores and opens up opportunities to further exploit bioorthogonal chemistry in in vivo imaging.
生物正交化学在分子光学成像中的进展在于扩展荧光团的种类,这些荧光团可以在生物正交连接后发生荧光信号变化。然而,大多数现有的生物正交激活荧光团仅通过分子内电荷转移机制发射浅层组织穿透可见光。在此,我们在设计近红外(NIR)四嗪(Tz)基花菁探针时报告了一个偶然的“扭曲诱导解聚(TIDA)”现象。Tz-环辛烯连接触发了花菁的 TIDA,将其七甲川链从 S-顺式转换为 S-反式构象。因此,在生物正交反应后,所得花菁的聚集趋势降低,导致 TIDA 诱导的荧光增强响应。这种 Tz-花菁探针在静脉注射后仅 5 分钟即可灵敏地区分活小鼠中的肿瘤。因此,这项工作发现了构建生物正交激活近红外荧光团的设计机制,并为进一步在体内成像中利用生物正交化学开辟了机会。
