Study on the Effect of Pre-Refinement and Heat Treatment on the Microstructure and Properties of Hypoeutectic Al-Si-Mg Alloy.

Hypoeutectic Al-Si-Mg alloys with a silicon content of around 10 wt % are widely used in the aerospace and automotive fields due to their excellent casting properties. However, the occurrence of "silicon poisoning" weakens the refinement effect of a conventional refiner system such as Al-5Ti-1B. In this paper, we proposed the "pre-refinement" method to avoid the "Si poisoning" to recover the refinement effect of Al-5Ti-1B. The core concept was to adjust the order of adding the Si element to form the TiAl before forming the Ti-Si intermetallic compound. To prove the effectiveness of the "pre-refinement" method, three alloys of "pre-refinement", "post-refinement", and "non-refinement" of an Al-10Si-0.48Mg alloy were prepared and characterized in as-cast and heat-treatment states. The results showed that the average grain diameter of the "pre-refinement" alloy was 60.19% smaller than that of the "post-refinement" one and 81.34% smaller than that of the "non-refinement" one, which demonstrated that the proposed method could effectively avoid the "silicon poisoning" effect. Based on a refined grain size, the "pre-refinement" Al-10Si-0.48Mg alloy showed the best optimization effect in mechanical properties after a solid-solution and subsequent aging heat treatments. The best mechanical properties were found in the "pre-refinement" alloy with 2 h of solid solution treatment and 10 h of aging treatment: a hardness of 92 HV, a tensile strength of 212 MPa, and an elongation of 20%.
