使用磁阻抗层析成像研究导体横截面上的电磁特性分布：建模与实验。

The Study of the Distribution of Electrical and Magnetic Properties over the Conductor Cross-Section Using Magnetoimpedance Tomography: Modeling and Experiment.

机构信息

Department of Physics, Pedagogical Institute, Irkutsk State University, 664003 Irkutsk, Russia.

Department of Magnetism and Magnetic Nanomaterials, Institute of Natural Sciences and Mathematics, Ural Federal University, 620002 Ekaterinburg, Russia.

出版信息

Sensors (Basel). 2022 Dec 5;22(23):9512. doi: 10.3390/s22239512.

DOI:10.3390/s22239512
PMID:36502214
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC9741072/
Abstract

A description of the method of magnetoimpedance tomography is presented. This method is based on the analysis of the frequency dependences of the impedance obtained in magnetic fields of various strengths. It allows one to determine the distribution of electrical and magnetic properties over the cross-section of the conductor, as well as their dependence on the magnetic field. The article proposes a specific approach to the implementation of the magnetoimpedance tomography method based on computer modeling by the finite element method. The results of this method are presented for composite CuBe/FeCoNi wires of the "highly conductive core-magnetically soft coating" type and amorphous rapidly quenched CoFeNbSiB wires.

摘要

介绍了磁阻抗层析成像方法。该方法基于对不同强度磁场中获得的阻抗频率依赖性的分析。它允许确定导体横截面上的电和磁特性的分布，以及它们对磁场的依赖性。本文提出了一种基于有限元方法的计算机建模实现磁阻抗层析成像方法的具体方法。该方法的结果是针对“高导芯-软磁涂层”型 CuBe/FeCoNi 复合线材和非晶快淬 CoFeNbSiB 线材给出的。
