School of Safety Science and Engineering, Henan Polytechnic University, Jiaozuo, China.
Key Laboratory of Public Security Management Technology, Shandong Management University, Jinan, China.
PLoS One. 2022 Dec 30;17(12):e0278521. doi: 10.1371/journal.pone.0278521. eCollection 2022.
With progressive urbanization and the development and utilization of urban underground space, underground urban complexes (UUCs) have been increasingly used. UUCs have brought much convenience to people's lives. However, due to their enclosed nature and complexity, it has been an urgent issue to avoid (or reduce) casualties and allow rapid and safe evacuation of people during an emergency. In this study, the evacuation simulation software Pathfinder was used. Based on the steering model, the variation of the total evacuation time and pedestrian flow at main exits with different simulated evacuation measures, congestion at key nodes and people's path selection were compared and analyzed. Then, the critical locations in the spatial layout of UUCs that were prone to evacuation bottleneck effects were focused on and determined. The evacuation effectiveness of UUCs in an emergency was studied to investigate the problems of emergency evacuation in UUCs. It is found that in UUCs, the bottleneck effects were likely to occur at stairway entrances and exits as well as supermarket checkout counters and caused severe congestion. These locations should be focused on during emergency evacuation. For key locations prone to evacuation bottlenecks, increasing the width of exits or setting up auxiliary evacuation channels could be an effective measure to improve evacuation efficiency. In addition, formulating rational evacuation rules can be a favorable measure for emergency evacuation. However, during the evacuation, the herd mentality in people has an uncertain (positive or negative) impact on evacuation effectiveness. Setting up diversion walls may improve evacuation efficiency and reduce congestion to a certain extent, while evacuation confusion and chaos are prone to occur after diversion. These findings in this study have significant implications for improving the emergency management of UUCs.
随着城市化进程的推进和城市地下空间的开发利用,地下城市综合体(UUC)得到了越来越多的应用。UUC 给人们的生活带来了诸多便利。然而,由于其封闭的性质和复杂性,避免(或减少)人员伤亡并在紧急情况下实现快速安全的人员疏散,已成为一个紧迫的问题。在本研究中,使用了疏散模拟软件 Pathfinder。基于转向模型,比较和分析了不同模拟疏散措施下总疏散时间和主出口处行人流量、关键节点处拥堵情况以及人员路径选择的变化。然后,关注并确定 UUC 空间布局中容易出现疏散瓶颈效应的关键位置。研究了 UUC 在紧急情况下的疏散效率,以探讨 UUC 中紧急疏散的问题。研究发现,在 UUC 中,楼梯进出口、超市收银台等位置容易出现瓶颈效应,导致严重拥堵。在紧急疏散时应重点关注这些位置。对于容易出现疏散瓶颈的关键位置,增加出口宽度或设置辅助疏散通道可能是提高疏散效率的有效措施。此外,制定合理的疏散规则也可以是紧急疏散的有利措施。然而,在疏散过程中,人们的从众心理对疏散效果具有不确定的(积极或消极)影响。设置分流墙在一定程度上可以提高疏散效率并减少拥堵,但分流后容易出现疏散混乱和混乱。本研究的这些发现对改善 UUC 的应急管理具有重要意义。
