用于电磁屏蔽应用的含碳纳米管多层复合材料

Multilayered Composites with Carbon Nanotubes for Electromagnetic Shielding Application.

作者信息

Bertašius Povilas, Plyushch Artyom, Macutkevič Jan, Banys Jūras, Selskis Algirdas, Platnieks Oskars, Gaidukovs Sergejs

机构信息

Faculty of Physics, Vilnius University, Sauletekio Av. 3, LT-10257 Vilnius, Lithuania.

Department of Structural Analysis of Materials, Center for Physical Science and Technology, Sauletekio Av. 3, LT-10257 Vilnius, Lithuania.

出版信息

Polymers (Basel). 2023 Feb 20;15(4):1053. doi: 10.3390/polym15041053.


DOI:10.3390/polym15041053
PMID:36850335
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC9963311/
Abstract

Bulk polylactic acid (PLA)/multiwall carbon nanotube (MWCNT) composites were prepared and investigated in wide frequency ranges (20 Hz-1 MHz and 24-40 GHz). It was determined that the percolation threshold in bulk PLA/MWCNT composites is close to 0.2 vol.% MWCNT. However, the best microwave dielectric properties and absorption were observed in composites with 3.0-5.0 vol.% MWCNT. Therefore, for future investigations, we selected layered (laminate) polymeric structures with gradual changes in MWCNT concentration from 0.2 to 8.0 vol.% MWCNT. Two approaches to laminate structure designs were examined and compared: a five-layer composite and a nine-layer composite that included four pure PLA middle layers. The addition of MWCNT enhanced the elastic modulus by up to 1.4-fold and tensile strength by up to 1.2-fold, with the best performance achieved at 5.0 vol.% loading. High microwave shielding was observed for these layered PLA/MWCNT structures with a gradient change in MWCNT concentration (up to 26 dB in both transmission and absorption coefficients) in the broad frequency range (from 24 to 40 GHz). Obtained structures are highly anisotropic, and the absorption coefficient is 2-5 dB higher in the direction of MWCNT concentration increase; however, the transmission coefficient is the same in both directions. The properties of microwave absorption are mainly unaffected by the additional polymeric layers. The absorption of the layered structure is greater than the absorption of single-layer composites with an optimal MWCNT concentration of the same thickness. The proposed laminate structure design is promising in the field of efficient electromagnetic shielding.

摘要

制备了块状聚乳酸(PLA)/多壁碳纳米管(MWCNT)复合材料,并在宽频率范围(20 Hz - 1 MHz和24 - 40 GHz)内进行了研究。结果表明,块状PLA/MWCNT复合材料的渗流阈值接近0.2体积%的MWCNT。然而,在MWCNT含量为3.0 - 5.0体积%的复合材料中观察到了最佳的微波介电性能和吸收性能。因此,为了未来的研究,我们选择了MWCNT浓度从0.2到8.0体积%逐渐变化的层状(层压板)聚合物结构。研究并比较了两种层压板结构设计方法:一种是五层复合材料,另一种是包含四个纯PLA中间层的九层复合材料。MWCNT的添加使弹性模量提高了1.4倍,拉伸强度提高了1.2倍,在5.0体积%的负载量下性能最佳。对于这些MWCNT浓度呈梯度变化的层状PLA/MWCNT结构,在宽频率范围(24至40 GHz)内观察到了高微波屏蔽性能(传输和吸收系数均高达26 dB)。所获得的结构具有高度各向异性,在MWCNT浓度增加的方向上吸收系数高2 - 5 dB;然而,两个方向上的传输系数相同。微波吸收性能主要不受额外聚合物层的影响。层状结构的吸收大于相同厚度且MWCNT浓度最佳的单层复合材料的吸收。所提出的层压板结构设计在高效电磁屏蔽领域具有广阔前景。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/472591200d9b/polymers-15-01053-g005a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/aefb33cbb05c/polymers-15-01053-g001a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/377633c5c5b0/polymers-15-01053-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/386eed123b8a/polymers-15-01053-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/684c5ab2f6d0/polymers-15-01053-g004a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/472591200d9b/polymers-15-01053-g005a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/aefb33cbb05c/polymers-15-01053-g001a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/377633c5c5b0/polymers-15-01053-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/386eed123b8a/polymers-15-01053-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/684c5ab2f6d0/polymers-15-01053-g004a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4c9e/9963311/472591200d9b/polymers-15-01053-g005a.jpg
