磁悬浮系统用于密度的量程/灵敏度可调测量。

A Magnetic Levitation System for Range/Sensitivity-Tunable Measurement of Density.

机构信息

Key Laboratory of Flexible Electronics (KLOFE), School of Flexible Electronics (Future Technologies) & Institute of Advanced Materials (IAM), Nanjing Tech University (NanjingTech), 30 South Puzhu Road, Nanjing 211816, China.

Xi'an Institute of Flexible Electronics, Northwestern Polytechnical University, 127 West Youyi Road, Xi'an 710072, China.

出版信息

Sensors (Basel). 2023 Apr 13;23(8):3955. doi: 10.3390/s23083955.

Abstract

Magnetic levitation (MagLev) is a promising density-based analytical technique with numerous applications. Several MagLev structures with different levels of sensitivity and range have been studied. However, these MagLev structures can seldom satisfy the different performance requirements simultaneously, such as high sensitivity, wide measurement range, and easy operation, which have prevented them from being widely used. In this work, a tunable MagLev system was developed. It is confirmed by numerical simulation and experiments that this system possesses a high resolution down to 10 g/cm or even higher compared to the existing systems. Meanwhile, the resolution and range of this tunable system can be adjusted to meet different requirements of measurement. More importantly, this system can be operated simply and conveniently. This bundle of characteristics demonstrates that the novel tunable MagLev system could be handily applied in various density-based analyses on demand, which would greatly expand the ability of MagLev technology.

摘要

磁悬浮(MagLev)是一种很有前途的基于密度的分析技术,具有许多应用。已经研究了几种具有不同灵敏度和范围的 MagLev 结构。然而,这些 MagLev 结构很少能够同时满足不同的性能要求,例如高灵敏度、宽测量范围和易于操作,这使得它们无法得到广泛应用。在这项工作中,开发了一种可调谐的 MagLev 系统。数值模拟和实验证实,与现有系统相比,该系统的分辨率高达 10 g/cm,甚至更高。同时,该可调系统的分辨率和范围可以进行调整以满足不同测量要求。更重要的是,该系统操作简单方便。这一系列特点表明,新型可调谐 MagLev 系统可以方便地应用于各种基于密度的按需分析,这将极大地扩展 MagLev 技术的能力。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/85de/10143956/35fc7d814c64/sensors-23-03955-g001.jpg
