利用混合光声超声成像对高强度聚焦超声加热和空化进行实时评估。

Real-time assessment of high-intensity focused ultrasound heating and cavitation with hybrid optoacoustic ultrasound imaging.

作者信息

Özsoy Çağla, Lafci Berkan, Reiss Michael, Deán-Ben Xosé Luís, Razansky Daniel

机构信息

Institute for Biomedical Engineering and Institute of Pharmacology and Toxicology, Faculty of Medicine, University of Zurich, Switzerland.

Institute for Biomedical Engineering, Department of Information Technology and Electrical Engineering, ETH Zurich, Switzerland.

出版信息

Photoacoustics. 2023 May 10;31:100508. doi: 10.1016/j.pacs.2023.100508. eCollection 2023 Jun.

Abstract

High-intensity focused ultrasound (HIFU) enables localized ablation of biological tissues by capitalizing on the synergistic effects of heating and cavitation. Monitoring of those effects is essential for improving the efficacy and safety of HIFU interventions. Herein, we suggest a hybrid optoacoustic-ultrasound (OPUS) approach for real-time assessment of heating and cavitation processes while providing an essential anatomical reference for accurate localization of the HIFU-induced lesion. Both effects could clearly be observed by exploiting the temperature dependence of optoacoustic (OA) signals and the strong contrast of gas bubbles in pulse-echo ultrasound (US) images. The differences in temperature increase and its rate, as recorded with a thermal camera for different HIFU pressures, evinced the onset of cavitation at the expected pressure threshold. The estimated temperatures based on OA signal variations were also within 10-20 % agreement with the camera readings for temperatures below the coagulation threshold (∼50 °C). Experiments performed in excised tissues as well as in a mouse demonstrate that both heating and cavitation effects can be effectively visualized and tracked using the OPUS approach. The good sensitivity of the suggested method for HIFU monitoring purposes was manifested by a significant increase in contrast-to-noise ratio within the ablated region by > 10 dB and > 5 dB for the OA and US images, respectively. The hybrid OPUS-based monitoring approach offers the ease of handheld operation thus can readily be implemented in a bedside setting to benefit several types of HIFU treatments used in the clinics.

摘要

高强度聚焦超声(HIFU)通过利用热效应和空化效应的协同作用实现对生物组织的局部消融。监测这些效应对于提高HIFU干预的疗效和安全性至关重要。在此,我们提出一种混合光声-超声(OPUS)方法,用于实时评估加热和空化过程,同时为准确确定HIFU诱导损伤的位置提供重要的解剖学参考。通过利用光声(OA)信号的温度依赖性和脉冲回波超声(US)图像中气泡的强烈对比度,可以清楚地观察到这两种效应。用热成像仪记录的不同HIFU压力下的温度升高及其速率差异,表明在预期的压力阈值处发生了空化。对于低于凝固阈值(约50°C)的温度,基于OA信号变化估计的温度与热成像仪读数的偏差也在10%-20%以内。在离体组织以及小鼠体内进行的实验表明,使用OPUS方法可以有效地可视化和跟踪加热和空化效应。所建议方法用于HIFU监测的良好灵敏度表现为,消融区域内的对比噪声比显著增加,OA图像和US图像分别增加>10 dB和>5 dB。基于OPUS的混合监测方法操作简便,因此可以很容易地在床边实施,以惠及临床上使用的几种类型的HIFU治疗。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/93c1/10203775/23f3a761fdf1/gr1.jpg
