Zhong Haoyin, Zhang Qi, Yu Junchen, Zhang Xin, Wu Chao, An Hang, Ma Yifan, Wang Hao, Zhang Jun, Zhang Yong-Wei, Diao Caozheng, Yu Zhi Gen, Xi Shibo, Wang Xiaopeng, Xue Junmin
Department of Materials Science and Engineering, National University of Singapore, Singapore, 117575, Singapore.
Institute of Sustainability for Chemical, Energy and Environment (ISCE2), Agency for Science, Technology and Research, Singapore, 627833, Singapore.
Nat Commun. 2023 Nov 18;14(1):7488. doi: 10.1038/s41467-023-43302-2.
A coupled oxygen evolution mechanism (COM) during oxygen evolution reaction (OER) has been reported in nickel oxyhydroxides (NiOOH)-based materials by realizing e band (3d electron states with e symmetry) broadening and light irradiation. However, the link between the e band broadening extent and COM-based OER activities remains unclear. Here, NiFeOOH (x = 0, 0.05, 0,2) are prepared to investigate the underlying mechanism governing COM-based activities. It is revealed that in low potential region, realizing stronger e band broadening could facilitate the OH deprotonation. Meanwhile, in high potential region where the photon utilization is the rate-determining step, a stronger e band broadening would widen the non-overlapping region between d and a orbitals, thereby enhancing photon utilization efficiency. Consequently, a stronger e band broadening could effectuate more efficient OER activities. Moreover, we demonstrate the universality of this concept by extending it to reconstruction-derived X-NiOOH (X = NiS, NiSe, NiP) with varying extent of e band broadening. Such an understanding of the COM would provide valuable guidance for the future development of highly efficient OER electrocatalysts.
通过实现e带(具有e对称性的3d电子态)展宽和光照射,在基于羟基氧化镍(NiOOH)的材料中报道了析氧反应(OER)过程中的耦合析氧机制(COM)。然而,e带展宽程度与基于COM的OER活性之间的联系仍不清楚。在此,制备了NiFeOOH(x = 0、0.05、0.2)以研究控制基于COM的活性的潜在机制。结果表明,在低电位区域,实现更强的e带展宽可以促进OH去质子化。同时,在光子利用是速率决定步骤的高电位区域,更强的e带展宽会扩大d和a轨道之间的非重叠区域,从而提高光子利用效率。因此,更强的e带展宽可以实现更高效的OER活性。此外,我们通过将其扩展到具有不同e带展宽程度的重构衍生X-NiOOH(X = NiS、NiSe、NiP)来证明这一概念的普遍性。对COM的这种理解将为高效OER电催化剂的未来发展提供有价值的指导。
