Thermal Regeneration of Spent Sand with Furfuryl Binder from an Ecological and Economic Point of View.

The recovery of the grain matrix from spent moulding sand is a constant challenge in making the best possible use of the deposits of quartz sand material, as well as in protecting them. In the case of spent sand with organic binders, the best method to recover the grain matrix is thermal regeneration. However, this method is expensive and requires adequate attention to the emission of harmful compounds into the atmosphere. This paper presents a new concept for implementing the thermal regeneration process. A suitable regeneration temperature was adopted for the furfuryl binder moulding sand, and a change in the design of the device was introduced in the area of the utilisation of gases generated during the combustion of the spent binder. To confirm the assumptions made, and to assess the appropriate suitability of the material recovered, the technological parameters of the material obtained were verified, namely, ignition losses, sieve analysis, bending strength, and pH value. The consumption of media for the process was also analysed from an economic point of view, as well as the emission of BTEX (a mixture of volatile aromatic hydrocarbons-benzene, toluene and three isomers of xylene) gases under different conditions of the process. On the basis of the research conducted, it was concluded that lowering the regeneration temperature of regeneration does not adversely affect the technological parameters of the moulding sand on the regenerate matrix. Changing the design of the regenerator does not result in increased emissions of harmful substances to the environment. Studies indicate that the appropriate setting of thermal regeneration parameters and the optimal design of the employed equipment are favourable factors in reducing the cost of the process while not compromising the quality of the moulding sand and the environmental impact.
