Study of the Impact of Data Compression on the Energy Consumption Required for Data Transmission in a Microcontroller-Based System.

As the number of Internet of Things (IoT) devices continues to rise dramatically each day, the data generated and transmitted by them follow similar trends. Given that a significant portion of these embedded devices operate on battery power, energy conservation becomes a crucial factor in their design. This paper aims to investigate the impact of data compression on the energy consumption required for data transmission. To achieve this goal, we conduct a comprehensive study using various transmission modules in a severely resource-limited microcontroller-based system designed for battery power. Our study evaluates the performance of several compression algorithms, conducting a detailed analysis of computational and memory complexity, along with performance metrics. The primary finding of our study is that by carefully selecting an algorithm for compressing different types of data before transmission, a significant amount of energy can be saved. Moreover, our investigation demonstrates that for a battery-powered embedded device transmitting sensor data based on the STM32F411CE microcontroller, the recommended transmission module is the nRF24L01+ board, as it requires the least amount of energy to transmit one byte of data. This module is most effective when combined with the LZ78 algorithm for optimal energy and time efficiency. In the case of image data, our findings indicate that the use of the JPEG algorithm for compression yields the best results. Overall, our research underscores the importance of selecting appropriate compression algorithms tailored to specific data types, contributing to enhanced energy efficiency in IoT devices.
