Numerous brain diseases have been attributed to abnormalities in the connections of neural circuits. Exploration of neural circuits may give enlightenment in treating some intractable brain diseases. Here, we screened all publications on neural circuits in the Web of Science database from 2007 to 2022 and analyzed the research trends through VOSviewer, CiteSpace, Microsoft Excel 2019, and Origin. The findings revealed a consistent upward trend in research on neural circuits during this period. The United States emerged as the leading contributor, followed by China and Japan. Among the top 10 institutions with the largest number of publications, both the United States and China have a strong presence. Notably, the Chinese Academy of Sciences demonstrated the highest publication output, closely followed by Stanford University. In terms of influential authors, Karl Deisseroth stood out as one of the most prominent investigators. During this period, the majority of publications and citations on neural circuit research were found in highly influential journals including NEURON, NATURE JOURNAL OF NEUROSCIENCE, and so forth. Keyword clustering analysis highlighted the increasing focus on neural circuits and photogenetics in neuroscience research, and the reconstruction of neural circuits has emerged as a crucial research direction in brain science. In conclusion, over the past 15 years, the increasing high-quality publications have facilitated research development of neural circuits, indicating a promising prospect for investigations on neurological and psychiatric diseases.
