Wang Quanjing, Zhang Ru, Chen Qingkui, Duan Ran
School of Mechanical and Electronic Engineering, Shandong Jianzhu University, Jinan 250101, China.
Micromachines (Basel). 2024 May 10;15(5):639. doi: 10.3390/mi15050639.
Silicon carbide (SiC) is a promising semiconductor material as well as a challenging material to machine, owing to its unique characteristics including high hardness, superior thermal conductivity, and chemical inertness. The ultrafast nature of femtosecond lasers enables precise and controlled material removal and modification, making them ideal for SiC processing. In this review, we aim to provide an overview of the process properties, progress, and applications by discussing the various methodologies involved in femtosecond laser processing of SiC. These methodologies encompass direct processing, composite processing, modification of the processing environment, beam shaping, etc. In addition, we have explored the myriad applications that arise from applying femtosecond laser processing to SiC. Furthermore, we highlight recent advancements, challenges, and future prospects in the field. This review provides as an important direction for exploring the progress of femtosecond laser micro/nano processing, in order to discuss the diversity of processes used for manufacturing SiC devices.
碳化硅(SiC)是一种很有前景的半导体材料,同时也是一种难以加工的材料,这是由于其具有包括高硬度、卓越的热导率和化学惰性在内的独特特性。飞秒激光的超快特性能够实现精确且可控的材料去除与改性,使其成为碳化硅加工的理想选择。在本综述中,我们旨在通过讨论碳化硅飞秒激光加工所涉及的各种方法,对其工艺特性、进展及应用进行概述。这些方法包括直接加工、复合加工、加工环境改性、光束整形等。此外,我们还探究了将飞秒激光加工应用于碳化硅所带来的众多应用。再者,我们强调了该领域的最新进展、挑战及未来前景。本综述为探索飞秒激光微纳加工的进展提供了一个重要方向,以便讨论用于制造碳化硅器件的工艺多样性。
