Laboratory of Biomedical Engineering, Faculty of Chemical and Process Engineering, Warsaw University of Technology, Waryńskiego 1, Warsaw 00-645, Poland.
Doctoral School of Warsaw University of Technology, Plac Politechniki 1, Warsaw 00-661, Poland.
ACS Biomater Sci Eng. 2024 Jul 8;10(7):4388-4399. doi: 10.1021/acsbiomaterials.4c00051. Epub 2024 Jun 10.
In this study, fibrous polyurethane (PU) materials with average fiber diameter of 200, 500, and 1000 nm were produced using a solution blow spinning (SBS) process. The effects of the rotation speed of the collector (in the range of 200-25 000 rpm) on the fiber alignment and diameter were investigated. The results showed that fiber alignment was influenced by the rotation speed of the collector, and such alignment was possible when the fiber diameter was within a specific range. Homogeneously oriented fibers were obtained only for a fiber diameter ≥500 nm. Moreover, the changes in fiber orientation and fiber diameter (resulting from changes in the rotation speed of the collector) were more noticeable for materials with an average fiber diameter of 1000 nm in comparison to 500 nm, which suggests that the larger the fiber diameter, the better the controlled architectures that can be obtained. The porosity of the produced scaffolds was about 65-70%, except for materials with a fiber diameter of 1000 nm and aligned fibers, which had a higher porosity (76%). Thus, the scaffold pore size increased with increasing fiber diameter but decreased with increasing fiber alignment. The mechanical properties of fibrous materials strongly depend on the direction of stretching, whereby the fiber orientation influences the mechanical strength only for materials with a fiber diameter of 1000 nm. Furthermore, the fiber diameter and alignment affected the pericyte growth. Significant differences in cell growth were observed after 7 days of cell culture between materials with a fiber diameter of 1000 nm (cell coverage 96-99%) and those with a fiber diameter of 500 nm (cell coverage 70-90%). By appropriately setting the SBS process parameters, scaffolds can be easily adapted to the cell requirements, which is of great importance in producing complex 3D structures for guided tissue regeneration.
在这项研究中,使用溶液吹纺(SBS)工艺制备了平均纤维直径为 200、500 和 1000nm 的纤维状聚氨酯(PU)材料。研究了收集器转速(200-25000rpm 范围内)对纤维取向和直径的影响。结果表明,纤维取向受收集器转速的影响,只有在纤维直径处于特定范围内时才可能产生纤维取向。仅当纤维直径≥500nm 时才能获得均匀取向的纤维。此外,与平均纤维直径为 500nm 的材料相比,纤维直径为 1000nm 的材料的纤维取向和纤维直径(由收集器转速变化引起)的变化更为明显,这表明纤维直径越大,可获得的受控结构越好。所制备的支架的孔隙率约为 65-70%,除了纤维直径为 1000nm 且纤维取向的材料具有较高的孔隙率(76%)之外。因此,支架的孔径随着纤维直径的增加而增加,但随着纤维取向的增加而减小。纤维材料的机械性能强烈依赖于拉伸方向,因此纤维取向仅对纤维直径为 1000nm 的材料的机械强度有影响。此外,纤维直径和取向影响周细胞的生长。在细胞培养 7 天后,观察到纤维直径为 1000nm 的材料(细胞覆盖率 96-99%)和纤维直径为 500nm 的材料(细胞覆盖率 70-90%)之间的细胞生长存在显著差异。通过适当设置 SBS 工艺参数,可以轻松地使支架适应细胞的要求,这对于生产用于引导组织再生的复杂 3D 结构非常重要。
