High-fidelity sub-petabit-per-second self-homodyne fronthaul using broadband electro-optic combs.

With the exponential growth in data density and user ends of wireless networks, fronthaul is tasked with supporting aggregate bandwidths exceeding thousands of gigahertz while accommodating high-order modulation formats. However, it must address the bandwidth and noise limitations imposed by optical links and devices in a cost-efficient manner. Here we demonstrate a high-fidelity fronthaul system enabled by self-homodyne digital-analog radio-over-fiber superchannels, using a broadband electro-optic comb and uncoupled multicore fiber. This self-homodyne superchannel architecture not only offers capacity boosting but also supports carrier-recovery-free reception. Our approach achieves a record-breaking 15,000 GHz aggregated wireless bandwidth, corresponding to a 0.879 Pb/s common public radio interface (CPRI) equivalent data rate. Higher-order formats up to 1,048,576 quadrature-amplitude-modulated (QAM) are showcased at a 100 Tb/s class data rate. Furthermore, we employ a packaged on-chip electro-optic comb as the sole optical source to reduce the cost, supporting a data rate of 100.5 Tb/s with the 1024-QAM format. These demonstrations propel fronthaul into the era of Pb/s-level capacity and exhibit the promising potential of integrated-photonics implementation, pushing the boundaries to new heights in terms of capacity, fidelity, and cost.
