使用mDixon Quant磁共振成像(MRI)评估腰椎旁肌肉形态:一项针对健康受试者的横断面研究。

Assessment of lumbar paraspinal muscle morphology using mDixon Quant magnetic resonance imaging (MRI): a cross-sectional study in healthy subjects.

作者信息

Krkoska Peter, Kokosova Viktoria, Dostal Marek, Vlazna Daniela, Kerkovsky Milos, Straka Matej, Gerstberger Radim, Matulova Katerina, Ovesna Petra, Adamova Blanka

机构信息

Department of Neurology, Center for Neuromuscular Diseases (Associated National Center in the European Reference Network ERN EURO-NMD), University Hospital Brno, Brno, Czechia.

Faculty of Medicine, Masaryk University, Brno, Czechia.

出版信息

Quant Imaging Med Surg. 2024 Aug 1;14(8):6015-6035. doi: 10.21037/qims-23-1796. Epub 2024 Jul 26.


DOI:10.21037/qims-23-1796
PMID:39144006
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC11320528/
Abstract

BACKGROUND: Lumbar paraspinal muscles (LPM) are a part of the deep spinal stabilisation system and play an important role in stabilising the lumbar spine and trunk. Inadequate function of these muscles is thought to be an essential aetiological factor in low back pain, and several neuromuscular diseases are characterised by dysfunction of LPM. The main aims of our study were to develop a methodology for LPM assessment using advanced magnetic resonance imaging (MRI) methods, including a manual segmentation process, to confirm the measurement reliability, to evaluate the LPM morphological parameters [fat fraction (FF), total muscle volume (TMV) and functional muscle volume (FMV)] in a healthy population, to study the influence of physiological factors on muscle morphology, and to build equations to predict LPM morphological parameters in a healthy population. METHODS: This prospective cross-sectional observational comparative single-centre study was conducted at the University Hospital in Brno, enrolling healthy volunteers from April 2021 to March 2023. MRI of the lumbar spine and LPM (erector spinae muscle and multifidus muscle) were performed using a 6-point Dixon gradient echo sequence. The segmentation of the LPM and the control muscle (psoas muscle) was done manually to obtain FF and TMV in a range from Th12/L1 to L5/S1. Intra-rater and inter-rater reliability were evaluated. Linear regression models were constructed to assess the effect of physiological factors on muscle FF, TMV and FMV. RESULTS: We enrolled 90 healthy volunteers (median age 38 years, 45 men). The creation of segmentation masks and the assessment of FF and TMV proved reliable (Dice coefficient 84% to 99%, intraclass correlation coefficient ≥0.97). The univariable models showed that FF of LPM was influenced the most by age (39.6% to 44.8% of variability, P<0.001); TMV and FMV by subject weight (34.9% to 67.6% of variability, P<0.001) and sex (24.7% to 64.1% of variability, P<0.001). Multivariable linear regression models for FF of LPM included age, body mass index and sex, with R-squared values ranging from 45.4% to 51.1%. Models for volumes of LPM included weight, age and sex, with R-squared values ranged from 37.4% to 76.8%. Equations were developed to calculate predicted FF, TMV and FMV for each muscle. CONCLUSIONS: A reliable methodology has been developed to assess the morphological parameters (biomarkers) of the LPM. The morphological parameters of the LPM are significantly influenced by physiological factors. Equations were constructed to calculate the predicted FF, TMV and FMV of individual muscles in relation to anthropometric parameters, age, and sex. This study, which presented LPM assessment methodology and predicted values of LPM morphological parameters in a healthy population, could improve our understanding of diseases involving LPM (low back pain and some neuromuscular diseases).

摘要

背景:腰椎旁肌肉(LPM)是深部脊柱稳定系统的一部分,在稳定腰椎和躯干方面发挥着重要作用。这些肌肉功能不足被认为是腰痛的一个重要病因,并且几种神经肌肉疾病的特征是LPM功能障碍。我们研究的主要目的是开发一种使用先进磁共振成像(MRI)方法评估LPM的方法,包括手动分割过程,以确认测量的可靠性,评估健康人群中LPM的形态学参数[脂肪分数(FF)、总肌肉体积(TMV)和功能性肌肉体积(FMV)],研究生理因素对肌肉形态的影响,并建立方程来预测健康人群中LPM的形态学参数。 方法:这项前瞻性横断面观察性比较单中心研究在布尔诺大学医院进行,于2021年4月至2023年3月招募健康志愿者。使用6点狄克逊梯度回波序列对腰椎和LPM(竖脊肌和多裂肌)进行MRI检查。通过手动对LPM和对照肌肉(腰大肌)进行分割,以获得从胸12/腰1到腰5/骶1范围内的FF和TMV。评估了评分者内和评分者间信度。构建线性回归模型以评估生理因素对肌肉FF、TMV和FMV的影响。 结果:我们招募了90名健康志愿者(中位年龄38岁,4​​5名男性)。分割掩码的创建以及FF和TMV的评估被证明是可靠的(骰子系数84%至99%,组内相关系数≥0.97)。单变量模型显示,LPM的FF受年龄影响最大(变异性为39.6%至44.8%,P<0.001);TMV和FMV受受试者体重(变异性为34.9%至67.6%,P<0.001)和性别(变异性为​​24.7%至64.1%,P<0.001)影响。LPM的FF多变量线性回归模型包括年龄、体重指数和性别,决定系数值范围为45.4%至51.1%。LPM体积的模型包括体重、年龄和性别,决定系数值范围为37.4%至76.8%。开发了方程来计算每块肌肉的预测FF、TMV和FMV。 结论:已开发出一种可靠的方法来评估LPM的形态学参数(生物标志物)。LPM的形态学参数受生理因素的显著影响。构建了方程来计算与人体测量参数、年龄和性别相关的个体肌肉的预测FF、TMV和FMV。这项展示了LPM评估方法和健康人群中LPM形态学参数预测值的研究,可能会增进我们对涉及LPM的疾病(腰痛和一些神经肌肉疾病)的理解。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/e4101e481e7b/qims-14-08-6015-f6.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/f568a84343c8/qims-14-08-6015-f1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/00af2a3f73a5/qims-14-08-6015-f2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/0520b2b16f3e/qims-14-08-6015-f3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/ab209dd50951/qims-14-08-6015-f4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/6fdd85fc24a5/qims-14-08-6015-f5.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/e4101e481e7b/qims-14-08-6015-f6.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/f568a84343c8/qims-14-08-6015-f1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/00af2a3f73a5/qims-14-08-6015-f2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/0520b2b16f3e/qims-14-08-6015-f3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/ab209dd50951/qims-14-08-6015-f4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/6fdd85fc24a5/qims-14-08-6015-f5.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c055/11320528/e4101e481e7b/qims-14-08-6015-f6.jpg
