CRISPR-mediated megabase-scale transgene de-duplication to generate a functional single-copy full-length humanized DMD mouse model.

BACKGROUND

The development of sequence-specific precision treatments like CRISPR gene editing therapies for Duchenne muscular dystrophy (DMD) requires sequence humanized animal models to enable the direct clinical translation of tested strategies. The current available integrated transgenic mouse model containing the full-length human DMD gene, Tg(DMD)72Thoen/J (hDMDTg), has been found to have two copies of the transgene per locus in a tail-to-tail orientation, which does not accurately simulate the true (single) copy number of the DMD gene. This duplication also complicates analysis when testing CRISPR therapy editing outcomes, as large genetic alterations and rearrangements can occur between the cut sites on the two transgenes.

RESULTS

To address this, we performed long read nanopore sequencing on hDMDTg mice to better understand the structure of the duplicated transgenes. Following that, we performed a megabase-scale deletion of one of the transgenes by CRISPR zygotic microinjection to generate a single-copy, full-length, humanized DMD transgenic mouse model (hDMDTgSc). Functional, molecular, and histological characterisation shows that the single remaining human transgene retains its function and rescues the dystrophic phenotype caused by endogenous murine Dmd knockout.

CONCLUSIONS

Our unique hDMDTgSc mouse model simulates the true copy number of the DMD gene, and can potentially be used for the further generation of DMD disease models that would be better suited for the pre-clinical assessment and development of sequence specific CRISPR therapies.
