Enhanced Hybrid Nanogenerator Based on PVDF-HFP and PAN/BTO Coaxially Structured Electrospun Nanofiber.

Nanogenerators have garnered significant interest as environmentally friendly and potential energy-harvesting systems. Nanogenerators can be broadly classified into piezo-, tribo-, and hybrid nanogenerators. The hybrid nanogenerator used in this experiment is a nanogenerator that uses both piezo and tribo effects. These hybrid nanogenerators have the potential to be used in wearable electronics, health monitoring, IoT devices, and more. In addition, the versatility of the material application in electrospinning makes it an ideal complement to hybrid nanogenerators. However, despite their potential, several experimental variables, biocompatibility, and harvesting efficiency require improvement in the research field. In particular, maximizing the output voltage of the fibers is a significant challenge. Based on this premise, this study aims to characterize hybrid nanogenerators (HNGs) with varied structures and material combinations, with a focus on identifying HNGs that exhibit superior piezoelectric- and triboelectric-induced voltage. In this study, several HNGs based on coaxial structures were fabricated via electrospinning. PVDF-HFP and PAN, known for their remarkable electrospinning properties, were used as the primary materials. Six combinations of these two materials were fabricated and categorized into homo and hetero groups based on their composition. The output voltage of the hetero group surpassed that of the homo group, primarily because of the triboelectric-induced voltage. Specifically, the overall output voltage of the hetero group was higher. In addition, the combination group with the most favorable voltage characteristics combined PVDF-HFP@PAN(BTO) and PAN hollow, boasting an output voltage of approximately 3.5 V.
