Lv Jianrong, Liao Guangzhi, Liu Weidong, Wang Xiaoguang, Jing Yuqian, Liu Hongxian, Jiang Ruihai
School of Engineering Science, University of Chinese Academy of Sciences, Beijing 100049, China.
Institute of Porous Flow and Fluid Mechanics, Chinese Academy of Sciences, Langfang 065007, China.
Polymers (Basel). 2024 Dec 3;16(23):3405. doi: 10.3390/polym16233405.
Reservoir heterogeneity significantly affects reservoir flooding efficiency and the formation and distribution of residual oil. As an effective method for enhancing recovery, polymer-surfactant (SP) flooding has a complex mechanism of action in inhomogeneous reservoirs. In this study, the effect of reservoir heterogeneity on the SP drive was investigated by designing core parallel flooding experiments combined with NMR and CT scanning techniques, taking conglomerate reservoirs in a Xinjiang oilfield as the research object. The experimental results show that inter-layer heterogeneity significantly affects water flooding efficiency and SP driving in low-permeability cores-the larger the permeability difference is, the more obvious the effect is-while it has almost no effect on high-permeability cores. The limited recovery enhancement in low-permeability cores is mainly due to the small percentage of contributing pores. When the permeability difference undergoes an extreme increase, the polymer molecular weight is biased towards higher values; when the polymer molecular weight is fixed, the recovery enhancement of low-permeability cores may be comparable to that of high-permeability cores when the permeability difference is extremely small. However, the recovery enhancement of the former is smaller than that of the latter when the permeability difference is extremely large. Due to intra-layer heterogeneity, there is a serious fingering phenomenon in the flooding stage, while in the SP flooding stage, recovery enhancement is most significant in the 5-20 μm pore range. This study provides an important geological basis for the rational development of a chemical flooding programme.
储层非均质性显著影响储层驱油效率以及剩余油的形成与分布。作为提高采收率的有效方法,聚合物 - 表面活性剂(SP)驱在非均质储层中具有复杂的作用机理。本研究以新疆某油田的砾岩储层为研究对象,通过设计岩心并联驱替实验并结合核磁共振(NMR)和计算机断层扫描(CT)技术,研究了储层非均质性对SP驱的影响。实验结果表明,层间非均质性对低渗透岩心中的水驱效率和SP驱有显著影响——渗透率差异越大,影响越明显——而对高渗透岩心几乎没有影响。低渗透岩心中采收率提高有限主要是由于贡献孔隙的比例较小。当渗透率差异急剧增大时,聚合物分子量倾向于更高的值;当聚合物分子量固定时,渗透率差异极小的情况下,低渗透岩心的采收率提高可能与高渗透岩心相当。然而,当渗透率差异极大时,前者的采收率提高小于后者。由于层内非均质性,在水驱阶段存在严重的指进现象,而在SP驱阶段,采收率提高在5 - 20μm孔隙范围内最为显著。本研究为化学驱方案的合理开发提供了重要的地质依据。
