水稻病害检测:用于增强检测和移动兼容性的TLI - YOLO创新方法。

Rice Disease Detection: TLI-YOLO Innovative Approach for Enhanced Detection and Mobile Compatibility.

作者信息

Li Zhuqi, Wu Wangyu, Wei Bingcai, Li Hao, Zhan Jingbo, Deng Songtao, Wang Jian

机构信息

School of Computer and Control Engineering, Northeast Forestry University, Harbin 150006, China.

School of Computer Science, University of Liverpool, Liverpool L69 3DR, UK.

出版信息

Sensors (Basel). 2025 Apr 15;25(8):2494. doi: 10.3390/s25082494.

Abstract

As a key global food reserve, rice disease detection technology plays an important role in promoting food production, protecting ecological balance and supporting sustainable agricultural development. However, existing rice disease identification techniques face many challenges, such as low training efficiency, insufficient model accuracy, incompatibility with mobile devices, and the need for a large number of training datasets. This study aims to develop a rice disease detection model that is highly accurate, resource efficient, and suitable for mobile deployment to address the limitations of existing technologies. We propose the Transfer Layer iRMB-YOLOv8 (TLI-YOLO) model, which modifies some components of the YOLOv8 network structure based on transfer learning. The innovation of this method is mainly reflected in four key components. First, transfer learning is used to import the pretrained model weights into the TLI-YOLO model, which significantly reduces the dataset requirements and accelerates model convergence. Secondly, it innovatively integrates a new small object detection layer into the feature fusion layer, which enhances the detection ability by combining shallow and deep feature maps so as to learn small object features more effectively. Third, this study is the first to introduce the iRMB attention mechanism, which effectively integrates Inverted Residual Blocks and Transformers, and introduces deep separable convolution to maintain the spatial integrity of features, thus improving the efficiency of computational resources on mobile platforms. Finally, this study adopted the WIoUv3 loss function and added a dynamic non-monotonic aggregation mechanism to the standard IoU calculation to more accurately evaluate and penalize the difference between the predicted and actual bounding boxes, thus improving the robustness and generalization ability of the model. The final test shows that the TLI-YOLO model achieved 93.1% precision, 88% recall, 95% mAP, and a 90.48% F1 score on the custom dataset, with only 12.60 GFLOPS of computation. Compared with YOLOv8n, the precision improved by 7.8%, the recall rate improved by 7.2%, and mAP@.5 improved by 7.6%. In addition, the model demonstrated real-time detection capability on an Android device and achieved efficiency of 30 FPS, which meets the needs of on-site diagnosis. This approach provides important support for rice disease monitoring.

摘要

作为全球重要的粮食储备,水稻病害检测技术在促进粮食生产、保护生态平衡和支持农业可持续发展方面发挥着重要作用。然而,现有的水稻病害识别技术面临诸多挑战,如训练效率低、模型准确率不足、与移动设备不兼容以及需要大量训练数据集等。本研究旨在开发一种高精度、资源高效且适合移动部署的水稻病害检测模型,以解决现有技术的局限性。我们提出了迁移层iRMB - YOLOv8(TLI - YOLO)模型,该模型基于迁移学习对YOLOv8网络结构的一些组件进行了修改。此方法的创新主要体现在四个关键组件上。首先,利用迁移学习将预训练模型权重导入TLI - YOLO模型,这显著降低了对数据集的要求并加速了模型收敛。其次,它创新性地在特征融合层集成了一个新的小目标检测层,通过结合浅层和深层特征图来增强检测能力,从而更有效地学习小目标特征。第三,本研究首次引入iRMB注意力机制,该机制有效地整合了深度可分离卷积和变换器,并引入深度可分离卷积以保持特征的空间完整性,从而提高移动平台上计算资源的效率。最后,本研究采用了WIoUv3损失函数,并在标准IoU计算中添加了动态非单调聚合机制,以更准确地评估和惩罚预测边界框与实际边界框之间的差异,从而提高模型的鲁棒性和泛化能力。最终测试表明,TLI - YOLO模型在自定义数据集上实现了93.1%的精确率、88%的召回率、95%的平均精度均值(mAP)以及90.48%的F1分数,计算量仅为12.60 GFLOPS。与YOLOv8n相比,精确率提高了7.8%,召回率提高了7.2%,mAP@.5提高了7.6%。此外,该模型在安卓设备上展示了实时检测能力,实现了30帧每秒的效率,满足现场诊断需求。此方法为水稻病害监测提供了重要支持。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/2587/12031063/dde7a8845d41/sensors-25-02494-g001.jpg
