Alfayez Fayez, Agrachev Mikhail, Matter Fabian, Lehner Sandro, Sekar Arvindh, Caseri Walter, Hufenus Rudolf, Gaan Sabyasachi, Heuberger Manfred P
Department of Advanced Fibers, Empa Swiss Federal Laboratories for Materials Science and Technology, St Gallen CH-9014, Switzerland.
Department of Materials, ETH Zürich, Zürich CH-8093, Switzerland.
ACS Appl Mater Interfaces. 2025 May 14;17(19):28808-28821. doi: 10.1021/acsami.5c01780. Epub 2025 Apr 29.
The in situ reduction of silver oxide to metallic silver is of technological relevance for various applications, from conductive welding in electronics to silver (Ag) nanoparticle generation in reactive melt extrusion. This study revisits the redox reaction mechanisms involved in forming metallic silver particles through the reduction of silver(I) oxide (AgO) in an alkane and polymer melt environment and sheds light on the obtained particulate morphology. Liquid pentadecane was selected as a model alkane, and the observed redox chemistry and particle morphology were compared to the reactive melt extrusion in polyethylene. Unlike the well-studied reduction of metal salts in the presence of oxygen-containing organic materials, the reduction occurring in a pure alkane environment, namely the different particle morphology, is poorly understood. Our findings revealed that the primary byproducts of the reaction between AgO and pentadecane were CO and HO, with minor products including alkenes and oxidized alkanes. The reduction process was not linear, with AgO acting both as a radical initiator and a source of oxygen. Gas chromatography detected CO formation at a rather low temperature, as low as 70 °C during the reaction between AgO and pentadecane, indicating a highly oxidative process resembling catalyzed combustion. Analytical techniques, including electron paramagnetic resonance (EPR) spectroscopy, confirmed that radicals were involved in the redox process via ROO• and HOO• radical species typically found in hydrocarbon oxidation under oxygen conditions. We hypothesize that the reaction is predominantly a complete oxidation, with only a small fraction of incomplete oxidation. Our observations also indicated that the metallic Ag formed directly on the surface of AgO in what appeared to be a solid-solid surface reaction, leading to a final Ag morphology resembling fused particles. While the resulting morphology may seem suboptimal regarding particle dispersion and homogeneity, it still offers a large contact area percolated structure that is advantageous for applications such as electronics welding. We thus conclude that in a pure alkane environment, the redox reactions are confined to the surface of the original particles.
氧化银原位还原为金属银在各种应用中具有技术相关性,从电子领域的导电焊接到反应性熔融挤出中银(Ag)纳米颗粒的生成。本研究重新审视了在烷烃和聚合物熔体环境中通过氧化银(AgO)还原形成金属银颗粒所涉及的氧化还原反应机制,并阐明了所得颗粒形态。选择液态十五烷作为模型烷烃,并将观察到的氧化还原化学和颗粒形态与聚乙烯中的反应性熔融挤出进行比较。与在含氧有机材料存在下对金属盐还原的深入研究不同,在纯烷烃环境中发生的还原反应,即不同的颗粒形态,目前了解甚少。我们的研究结果表明,AgO与十五烷反应的主要副产物是CO和HO,次要产物包括烯烃和氧化烷烃。还原过程不是线性的,AgO既作为自由基引发剂又作为氧源。气相色谱检测到在相当低的温度下,即AgO与十五烷反应期间低至70°C时就有CO生成,这表明该过程是类似于催化燃烧的高度氧化过程。包括电子顺磁共振(EPR)光谱在内的分析技术证实,自由基通过在氧气条件下烃氧化中通常发现的ROO•和HOO•自由基物种参与氧化还原过程。我们假设该反应主要是完全氧化,只有一小部分是不完全氧化。我们的观察还表明,金属Ag直接在AgO表面形成,这似乎是一种固 - 固表面反应,导致最终的Ag形态类似于熔合颗粒。虽然所得形态在颗粒分散和均匀性方面可能看起来不太理想,但它仍然提供了一个具有大接触面积的渗滤结构,这对于诸如电子焊接等应用是有利的。因此,我们得出结论,在纯烷烃环境中,氧化还原反应局限于原始颗粒的表面。
