用于热激活延迟荧光的四面体铜(I)配合物:基于QM/MM模型的密度泛函基准研究

Tetrahedral Cu(I) Complexes for Thermally Activated Delayed Fluorescence: A Density Functional Benchmark Study with QM/MM Models.

作者信息

Eskelinen Toni, Karttunen Antti J

机构信息

Department of Chemistry and Materials Science, School of Chemical Engineering, Aalto University, Kemistintie 1, Espoo 02150, Finland.

出版信息

Inorg Chem. 2025 May 12;64(18):9150-9162. doi: 10.1021/acs.inorgchem.5c00761. Epub 2025 Apr 30.

DOI:10.1021/acs.inorgchem.5c00761
PMID:40305465
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC12076558/
Abstract

Tetrahedral Cu(I) complexes represent a major class of organometallic thermally activated delayed fluorescence (TADF) emitters. However, due to the d electronic structure and low-lying metal-to-ligand charge transfer (MLCT) states, these systems exhibit (pseudo) Jahn-Teller distortions in the excited state, resulting in tetrahedral to square planar geometry flattening. From a computational point of view, this poses a major challenge since theoretical studies are often conducted with isolated single molecule models. Such models are incapable of describing the suppressing effect of the surrounding solid-state environment on geometry relaxation and often result in overly relaxed excited-state geometries and inaccurate transition energies. Crystal models based on quantum mechanics/molecular mechanics (QM/MM) approaches have emerged as viable candidates for modeling the solid-state environment. Here, we report a study, conducted on 56 experimentally known tetrahedral Cu(I) TADF emitters, comparing the isolated and QM/MM models together with five commonly used density functionals. Our results show that while differences in ground-state geometries and excitation energies are small, significant deviations are observed in the excited-state geometries and fluorescence energies. Because of the added rigidity, the QM/MM models show less (pseudo) Jahn-Teller effect induced geometry flattening, which consequently results in blue-shifted fluorescence energies compared with isolated models.

摘要

四面体铜(I)配合物是有机金属热激活延迟荧光(TADF)发光体的主要类别。然而,由于d电子结构和低能级的金属到配体电荷转移(MLCT)态,这些体系在激发态表现出(伪) Jahn-Teller畸变,导致四面体到平面正方形几何结构的扁平化。从计算的角度来看,这带来了一个重大挑战,因为理论研究通常使用孤立的单分子模型进行。这样的模型无法描述周围固态环境对几何结构弛豫的抑制作用,并且常常导致过度弛豫的激发态几何结构和不准确的跃迁能量。基于量子力学/分子力学(QM/MM)方法的晶体模型已成为模拟固态环境的可行候选者。在此,我们报告一项针对56种实验已知的四面体铜(I) TADF发光体进行的研究,将孤立模型和QM/MM模型与五种常用的密度泛函进行比较。我们的结果表明,虽然基态几何结构和激发能的差异很小,但在激发态几何结构和荧光能方面观察到了显著偏差。由于增加了刚性,QM/MM模型显示出较少的(伪) Jahn-Teller效应引起的几何结构扁平化,因此与孤立模型相比,荧光能发生蓝移。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/90ec6fc6a039/ic5c00761_0003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/1478a1048e54/ic5c00761_0001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/27e88a09c0ed/ic5c00761_0002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/90ec6fc6a039/ic5c00761_0003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/1478a1048e54/ic5c00761_0001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/27e88a09c0ed/ic5c00761_0002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3a3c/12076558/90ec6fc6a039/ic5c00761_0003.jpg
